Sanyo LCD-32CA9S Service Manual

11
Mechanical Disassembly(LCD-37CA9S
Power board
LCD SCREEM
KEY & LED
BOARDS
main board
SUB board
（二）Chassis and Terminal Board Removal
1. Remove screws C , D and F, take the terminal board off.
2. Remove Screw E，take P Board off.
（
C: 1pcs, D: 2pcs
,
E
：
15pcs, F:2pcs)
D
C
F
