Sanyo LCD-32CA9S Service Manual

15
Chassis Electrical Parts List
Note: Parts order must contain Service Ref. No., Part No., and descriptions.

LOCATION C_PARTS_CODE DESCRIPTION
A013 013N5ZW
ELECTRICAL PARTS
EL901 1AV4T40B97800 LCD(T420HW01 V2)
SP901 1LB4A10B10600 SPEAKER
,
8
SP902 1LB4A10B10600 SPEAKER
,
8
SP903 1LB4A10B10500 SPEAKER
,
8
WCN1
-
660 1LB9W0ECM005D
NONSTANDARD WIRE
1LB4J11YA040N SOCKET
,
HOUSING 4P
1LB4J11YA100N SOCKET
,
HOUSING 10P
1LB4J11YA140N SOCKET
,
HOUSING 14P
1LB4J30B0010N TERMINAL
,
SOCKET
8DLO046 CUTTING WIRE
8DLR046 CUTTING WIRE
8DLW058 CUTTING WIRE
8214KG3R0 CUTTING TAPE
WCN2
-
661 1LB9W0CCM003
-
NONSTANDARD WIRE
1LB4J11YA100N SOCKET
,
HOUSING 10P
1LB4J11YA120N SOCKET
,
HOUSING 12P
1LB4J30B0010N TERMINAL
,
SOCKET
8DLR036 CUTTING WIRE
8DLW036 CUTTING WIRE
8214KG3R0 CUTTING TAPE
WSP9C 1LB9W06CM001A
NONSTANDARD WIRE
1LB4J11YA060N SOCKET
,
HOUSING 6P
1LB4J30B0010N TERMINAL
,
SOCKET
8DEW090XM CUTTING WIRE
WSP9L 1LB9W03CM001J
NONSTANDARD WIRE
WSP9R 1LB9W02CM001G
NONSTANDARD WIRE
W1701
-
70 1AA93CN07140X STANDARD WIRE
W1702
-
70 1AA99CM07100X STANDARD WIRE
W662
-
001 1AA95CM01160X STANDARD WIRE
W670
-
101 1AA92CN07160X STANDARD WIRE
W680
-
150 1AA9ECM07260X STANDARD WIRE
W681
-
704 1AA94CN07280X STANDARD WIRE
W7300 1LB4W30B13400 CORD 51PIN (LVDS)
W8001
-
19 1AA94CM07740X STANDARD WIRE
W8002
-
19 1AA97CM07480X STANDARD WIRE
W901 1AV4W10B19100
CORD
,
POWER
-
2
.
23MK
-
A1000 1AA0B10S264B0
ASSY
,
PWB
,
MAIN
+
RC
,
A101 1AA0B10S264BA ASSY
,
PWB
,
MAIN
,
N5ZW
A102 1LB4F1FCX0040 TUNERU/V
C001 CEXLB1V471VEN
ELECT 470U M
C002 CEXLB1V471VEN
ELECT 470U M
C003 CK1H474ZGBFNG
CERAMIC 0
.
47U Z
C004 CK1C105ZGAFNG
CERAMIC 1U Z
C005 CK1C105ZGAFNG
CERAMIC 1U Z
C006 CK1C105ZGAFNG
CERAMIC 1U Z
C007 CK1H474ZGBFNG
CERAMIC 0
.
47U Z
C008 CK1C105ZGAFNG
CERAMIC 1U Z
C009 CEXLB1H471VEN
ELECT 470U M
C010 CK1E224KLZBNG
CERAMIC 0
.
22U K
C011 CEXLB1H100VCG
ELECT 10U M
C011 CE1H100M1WANG
ELECT 10U M
C012 CKXAV1H104EAG CERAMIC0
.
1U K 50V

C012 CKXLB1H104YAG
CERAMIC 0
.
1U K
C012 CK1H104KGQBNG
CERAMIC 0
.
1U K
C013 CK1H474ZGBFNG
CERAMIC 0
.
47U Z
C014 CK1H474ZGBFNG
CERAMIC 0
.
47U Z
C015 CK1E224KLZBNG
CERAMIC 0
.
22U K
C016 CEXLB1H471VEN
ELECT 470U M
C017 CEXLB1V471VEN
ELECT 470U M
C018 CEXLB1V471VEN
ELECT 470U M
C019 CK1C105ZGAFNG
CERAMIC 1U Z
C020 CK1C105ZGAFNG
CERAMIC 1U Z
C021 CK1C105ZGAFNG
CERAMIC 1U Z
C022 CK1H474ZGBFNG
CERAMIC 0
.
47U Z
C024 CKXAV1H104EAG CERAMIC0
.
1U K 50V
C024 CKXLB1H104YAG
CERAMIC 0
.
1U K
C024 CK1H104KGQBNG
CERAMIC 0
.
1U K
C025 CEXLB1H100VCG
ELECT 10U M
C025 CE1H100M1WANG
ELECT 10U M
C026 CK1E224KLZBNG
CERAMIC 0
.
22U K
C027 CK1H474ZGBFNG
CERAMIC 0
.
47U Z
C028 CEXLB1V102TAN
ELECT 1000U M
C028 CEXLB1V102VDN
ELECT 1000U M
C029 CKXLB1H103YDG
CERAMIC 0
.
01U Z
C030 CKXAV1C224EAG
CERAMIC 0
.
22U K
C030 CK1C224KGQBNG
CERAMIC 0
.
22U K
C031 CK1C105ZGAFNG
CERAMIC 1U Z
C032 CE1C470M1WANG
ELECT 47U M
C033 CE1E101M1WANG
ELECT 100U M
C034 CE1E101M1WANG
ELECT 100U M
C035 CK1C105ZGAFNG
CERAMIC 1U Z
C037 CKXAV1H104EAG CERAMIC0
.
1U K 50V
C037 CKXLB1H104YAG
CERAMIC 0
.
1U K
C037 CK1H104KGQBNG
CERAMIC 0
.
1U K
C038 CK1H474ZGBFNG
CERAMIC 0
.
47U Z
C055 CE1V101M1VANG
ELECT 100U M
C056 CKXAV1C104EAG
CERAMIC 0
.
1U K
C056 CKXLB1C104YAG
CERAMIC 0
.
1U K
C056 CK1C104KGQBNG
CERAMIC 0
.
1U K
C057 CE1V101M1VANG
ELECT 100U M
C058 CKXAV1C104EAG
CERAMIC 0
.
1U K
C058 CKXLB1C104YAG
CERAMIC 0
.
1U K
C058 CK1C104KGQBNG
CERAMIC 0
.
1U K
C1002 CE1C221M1WANG
ELECT 220U M
C1005 CEXLB1C100VAG
ELECT 10U M
C1005 CE1C100M1WANG
ELECT 10U M
C1008 CEXLB1C100VAG
ELECT 10U M
C1008 CE1C100M1WANG
ELECT 10U M
C1009 CK1C225ZGAFNG
CERAMIC 2
.
2U Z
C101 CKXAV1C104EAG
CERAMIC 0
.
1U K
C101 CKXLB1C104YAG
CERAMIC 0
.
1U K
C101 CK1C104KGQBNG
CERAMIC 0
.
1U K
C1010 CEXLB1C100VAG
ELECT 10U M
C1010 CE1C100M1WANG
ELECT 10U M
C1011 CKXAV1C104EAG
CERAMIC 0
.
1U K
C1011 CKXLB1C104YAG
CERAMIC 0
.
1U K

LOCATION C_PARTS_CODE DESCRIPTION
A013 013N5ZW
ELECTRICAL PARTS
EL901 1AV4T40B97800 LCD(T420HW01 V2)
SP901 1LB4A10B10600 SPEAKER
,
8
SP902 1LB4A10B10600 SPEAKER
,
8
SP903 1LB4A10B10500 SPEAKER
,
8
WCN1
-
660 1LB9W0ECM005D
NONSTANDARD WIRE
1LB4J11YA040N SOCKET
,
HOUSING 4P
1LB4J11YA100N SOCKET
,
HOUSING 10P
1LB4J11YA140N SOCKET
,
HOUSING 14P
1LB4J30B0010N TERMINAL
,
SOCKET
8DLO046 CUTTING WIRE
8DLR046 CUTTING WIRE
8DLW058 CUTTING WIRE
8214KG3R0 CUTTING TAPE
WCN2
-
661 1LB9W0CCM003
-
NONSTANDARD WIRE
1LB4J11YA100N SOCKET
,
HOUSING 10P
1LB4J11YA120N SOCKET
,
HOUSING 12P
1LB4J30B0010N TERMINAL
,
SOCKET
8DLR036 CUTTING WIRE
8DLW036 CUTTING WIRE
8214KG3R0 CUTTING TAPE
WSP9C 1LB9W06CM001A
NONSTANDARD WIRE
1LB4J11YA060N SOCKET
,
HOUSING 6P
1LB4J30B0010N TERMINAL
,
SOCKET
8DEW090XM CUTTING WIRE
WSP9L 1LB9W03CM001J
NONSTANDARD WIRE
WSP9R 1LB9W02CM001G
NONSTANDARD WIRE
W1701
-
70 1AA93CN07140X STANDARD WIRE
W1702
-
70 1AA99CM07100X STANDARD WIRE
W662
-
001 1AA95CM01160X STANDARD WIRE
W670
-
101 1AA92CN07160X STANDARD WIRE
W680
-
150 1AA9ECM07260X STANDARD WIRE
W681
-
704 1AA94CN07280X STANDARD WIRE
W7300 1LB4W30B13400 CORD 51PIN (LVDS)
W8001
-
19 1AA94CM07740X STANDARD WIRE
W8002
-
19 1AA97CM07480X STANDARD WIRE
W901 1AV4W10B19100
CORD
,
POWER
-
2
.
23MK
-
A1000 1AA0B10S264B0
ASSY
,
PWB
,
MAIN
+
RC
,
A101 1AA0B10S264BA ASSY
,
PWB
,
MAIN
,
N5ZW
A102 1LB4F1FCX0040 TUNERU/V
C001 CEXLB1V471VEN
ELECT 470U M
C002 CEXLB1V471VEN
ELECT 470U M
C003 CK1H474ZGBFNG
CERAMIC 0
.
47U Z
C004 CK1C105ZGAFNG
CERAMIC 1U Z
C005 CK1C105ZGAFNG
CERAMIC 1U Z
C006 CK1C105ZGAFNG
CERAMIC 1U Z
C007 CK1H474ZGBFNG
CERAMIC 0
.
47U Z
C008 CK1C105ZGAFNG
CERAMIC 1U Z
C009 CEXLB1H471VEN
ELECT 470U M
C010 CK1E224KLZBNG
CERAMIC 0
.
22U K
C011 CEXLB1H100VCG
ELECT 10U M
C011 CE1H100M1WANG
ELECT 10U M
C012 CKXAV1H104EAG CERAMIC0
.
1U K 50V
