Mechanical Disassembly (LCD-32CA9S)
P o w e r
M a i n
SUB board
B u t t o n &
LED Boards
LCD Screen
C
F
（二）Chassis and Terminal Board Removal
1. Remove screws C , D and F, take the terminal board off.
2. Remove Screw E，take P Board off.
（
C: 1pcs, D: 2pcs
,
E
：
15pcs, F:2pcs)
D
