Sanyo LCD-32CA9S Service Manual

33
Chassis Electrical Parts List

L1900 1AV4L26B0130G INDUCTOR
,
600 OHM
L1900 1LB4L26B1090G INDUCTOR 600 OHM
PB1901 1AA4B10S04800 PWB
,
POWER
+
KEY
+
LC
PB1901 1AA4B10S0480B PWB
,
KEY
R1900 RGF1502JTCANL
MT
-
GLAZE 15K JA
R1901 RGF1502JTCANL
MT
-
GLAZE 15K JA
R1902 RGF1202JTCANL
MT
-
GLAZE 12K JA
R1903 RGF8201JTCANL
MT
-
GLAZE 8
.
2K JA
R1904 RGF1802JTCANL
MT
-
GLAZE 18K JA
R1905 RGF5602JTCANL
MT
-
GLAZE 56K JA
R1906 RGF1202JTCANL
MT
-
GLAZE 12K JA
R1907 RGF8201JTCANL
MT
-
GLAZE 8
.
2K JA
R1908 RGF1802JTCANL
MT
-
GLAZE 18K JA
R1909 RGFR000ZTCANL
MT
-
GLAZE 0
.
000 ZA
R1910 RGFR000ZTCANL
MT
-
GLAZE 0
.
000 ZA
R1911 RGFR000ZTCANL
MT
-
GLAZE 0
.
000 ZA
R1912 RGFR000ZTCANL
MT
-
GLAZE 0
.
000 ZA
SC1900 1AV4Z30B0220G SURGE
-
ABSORBER
SC1901 1AV4Z30B0220G SURGE
-
ABSORBER
SC1902 1AV4Z30B0220G SURGE
-
ABSORBER
SW1900 1LB4S10B01500 SWITCH
,
PUSH 1P
-
1TX1
SW1901 1LB4S10B01500 SWITCH
,
PUSH 1P
-
1TX1
SW1902 1LB4S10B01500 SWITCH
,
PUSH 1P
-
1TX1
SW1903 1LB4S10B01500 SWITCH
,
PUSH 1P
-
1TX1
SW1904 1LB4S10B01500 SWITCH
,
PUSH 1P
-
1TX1
SW1905 1LB4S10B01500 SWITCH
,
PUSH 1P
-
1TX1
SW1906 1LB4S10B01500 SWITCH
,
PUSH 1P
-
1TX1
ZD1900 DZUDZS10B
---
G
ZENER DIODE UDZS
-
TE
-
ZD1900 DZXLBXB10B
--
G
ZENER DIODE MM3Z
ZD1901 DZUDZS10B
---
G
ZENER DIODE UDZS
-
TE
-
ZD1901 DZXLBXB10B
--
G
ZENER DIODE MM3Z
ZD1902 DZUDZS10B
---
G
ZENER DIODE UDZS
-
TE
-
ZD1902 DZXLBXB10B
--
G
ZENER DIODE MM3Z
ZD1903 DZUDZS10B
---
G
ZENER DIODE UDZS
-
TE
-
ZD1903 DZXLBXB10B
--
G
ZENER DIODE MM3Z
ZD1904 DZUDZS10B
---
G
ZENER DIODE UDZS
-
TE
-
ZD1904 DZXLBXB10B
--
G
ZENER DIODE MM3Z
ZD1905 DZUDZS10B
---
G
ZENER DIODE UDZS
-
TE
-
ZD1905 DZXLBXB10B
--
G
ZENER DIODE MM3Z
ZD1906 DZUDZS10B
---
G
ZENER DIODE UDZS
-
TE
-
ZD1906 DZXLBXB10B
--
G
ZENER DIODE MM3Z
PB001 1AA4B10S04800 PWB
,
POWER
+
KEY
+
LC
PB001 1AA4B10S0480C PWB
,
LC
A3000 1AA0B10S26600 ASSY
,
PWB
,
USB
,
N5ZW
C700 CE0J220M1WANG
ELECT 22U M
C701 CKXAV1H103EAG
CERAMIC 0
.
01U K
C701 CKXLB1H103YAG
CERAMIC 0
.
01U K
C701 CK1H103KGQBNG
CERAMIC 0
.
01U K
C702 CKXAV1H103EAG
CERAMIC 0
.
01U K
C702 CKXLB1H103YAG
CERAMIC 0
.
01U K
C702 CK1H103KGQBNG
CERAMIC 0
.
01U K
C703 CCXAV1H220ABG CERAMIC22P J 50
.
0V
C703 CCXLB1H220ZBG
CERAMIC 22P J
C703 CC1H220JGQCNG
CERAMIC 22P J

LOCATION C_PARTS_CODE DESCRIPTION
A013 013N5ZW
ELECTRICAL PARTS
EL901 1AV4T40B97800 LCD(T420HW01 V2)
SP901 1LB4A10B10600 SPEAKER
,
8
SP902 1LB4A10B10600 SPEAKER
,
8
SP903 1LB4A10B10500 SPEAKER
,
8
WCN1
-
660 1LB9W0ECM005D
NONSTANDARD WIRE
1LB4J11YA040N SOCKET
,
HOUSING 4P
1LB4J11YA100N SOCKET
,
HOUSING 10P
1LB4J11YA140N SOCKET
,
HOUSING 14P
1LB4J30B0010N TERMINAL
,
SOCKET
8DLO046 CUTTING WIRE
8DLR046 CUTTING WIRE
8DLW058 CUTTING WIRE
8214KG3R0 CUTTING TAPE
WCN2
-
661 1LB9W0CCM003
-
NONSTANDARD WIRE
1LB4J11YA100N SOCKET
,
HOUSING 10P
1LB4J11YA120N SOCKET
,
HOUSING 12P
1LB4J30B0010N TERMINAL
,
SOCKET
8DLR036 CUTTING WIRE
8DLW036 CUTTING WIRE
8214KG3R0 CUTTING TAPE
WSP9C 1LB9W06CM001A
NONSTANDARD WIRE
1LB4J11YA060N SOCKET
,
HOUSING 6P
1LB4J30B0010N TERMINAL
,
SOCKET
8DEW090XM CUTTING WIRE
WSP9L 1LB9W03CM001J
NONSTANDARD WIRE
WSP9R 1LB9W02CM001G
NONSTANDARD WIRE
W1701
-
70 1AA93CN07140X STANDARD WIRE
W1702
-
70 1AA99CM07100X STANDARD WIRE
W662
-
001 1AA95CM01160X STANDARD WIRE
W670
-
101 1AA92CN07160X STANDARD WIRE
W680
-
150 1AA9ECM07260X STANDARD WIRE
W681
-
704 1AA94CN07280X STANDARD WIRE
W7300 1LB4W30B13400 CORD 51PIN (LVDS)
W8001
-
19 1AA94CM07740X STANDARD WIRE
W8002
-
19 1AA97CM07480X STANDARD WIRE
W901 1AV4W10B19100
CORD
,
POWER
-
2
.
23MK
-
A1000 1AA0B10S264B0
ASSY
,
PWB
,
MAIN
+
RC
,
A101 1AA0B10S264BA ASSY
,
PWB
,
MAIN
,
N5ZW
A102 1LB4F1FCX0040 TUNERU/V
C001 CEXLB1V471VEN
ELECT 470U M
C002 CEXLB1V471VEN
ELECT 470U M
C003 CK1H474ZGBFNG
CERAMIC 0
.
47U Z
C004 CK1C105ZGAFNG
CERAMIC 1U Z
C005 CK1C105ZGAFNG
CERAMIC 1U Z
C006 CK1C105ZGAFNG
CERAMIC 1U Z
C007 CK1H474ZGBFNG
CERAMIC 0
.
47U Z
C008 CK1C105ZGAFNG
CERAMIC 1U Z
C009 CEXLB1H471VEN
ELECT 470U M
C010 CK1E224KLZBNG
CERAMIC 0
.
22U K
C011 CEXLB1H100VCG
ELECT 10U M
C011 CE1H100M1WANG
ELECT 10U M
C012 CKXAV1H104EAG CERAMIC0
.
1U K 50V

C704 CCXAV1H220ABG CERAMIC22P J 50
.
0V
C704 CCXLB1H220ZBG
CERAMIC 22P J
C704 CC1H220JGQCNG
CERAMIC 22P J
C705 CCXAV1H101ABG
CERAMIC0
.
0001U J
C705 CCXLB1H101ZBG
CERAMIC 100P J
C705 CC1H101JGQCNG
CERAMIC 100P J
C706 CE0J101M1WANG
ELECT 100U M
C707 CKXAV1C104EAG
CERAMIC 0
.
1U K
C707 CKXLB1C104YAG
CERAMIC 0
.
1U K
C707 CK1C104KGQBNG
CERAMIC 0
.
1U K
C708 CKXAV1C104EAG
CERAMIC 0
.
1U K
C708 CKXLB1C104YAG
CERAMIC 0
.
1U K
C708 CK1C104KGQBNG
CERAMIC 0
.
1U K
C709 CKXAV1C104EAG
CERAMIC 0
.
1U K
C709 CKXLB1C104YAG
CERAMIC 0
.
1U K
C709 CK1C104KGQBNG
CERAMIC 0
.
1U K
C710 CKXAV1C104EAG
CERAMIC 0
.
1U K
C710 CKXLB1C104YAG
CERAMIC 0
.
1U K
C710 CK1C104KGQBNG
CERAMIC 0
.
1U K
C711 CKXAV1C104EAG
CERAMIC 0
.
1U K
C711 CKXLB1C104YAG
CERAMIC 0
.
1U K
C711 CK1C104KGQBNG
CERAMIC 0
.
1U K
C712 CKXAV1C104EAG
CERAMIC 0
.
1U K
C712 CKXLB1C104YAG
CERAMIC 0
.
1U K
C712 CK1C104KGQBNG
CERAMIC 0
.
1U K
C713 CKXAV1C104EAG
CERAMIC 0
.
1U K
C713 CKXLB1C104YAG
CERAMIC 0
.
1U K
C713 CK1C104KGQBNG
CERAMIC 0
.
1U K
C714 CKXAV1C104EAG
CERAMIC 0
.
1U K
C714 CKXLB1C104YAG
CERAMIC 0
.
1U K
C714 CK1C104KGQBNG
CERAMIC 0
.
1U K
C715 CKXAV1C104EAG
CERAMIC 0
.
1U K
C715 CKXLB1C104YAG
CERAMIC 0
.
1U K
C715 CK1C104KGQBNG
CERAMIC 0
.
1U K
C716 CE0J101M1WANG
ELECT 100U M
C717 CKXAV1C104EAG
CERAMIC 0
.
1U K
C717 CKXLB1C104YAG
CERAMIC 0
.
1U K
C717 CK1C104KGQBNG
CERAMIC 0
.
1U K
C718 CKXAV1C104EAG
CERAMIC 0
.
1U K
C718 CKXLB1C104YAG
CERAMIC 0
.
1U K
C718 CK1C104KGQBNG
CERAMIC 0
.
1U K
C719 CKXAV1C104EAG
CERAMIC 0
.
1U K
C719 CKXLB1C104YAG
CERAMIC 0
.
1U K
C719 CK1C104KGQBNG
CERAMIC 0
.
1U K
C720 CKXAV1C104EAG
CERAMIC 0
.
1U K
C720 CKXLB1C104YAG
CERAMIC 0
.
1U K
C720 CK1C104KGQBNG
CERAMIC 0
.
1U K
C721 CKXAV1C104EAG
CERAMIC 0
.
1U K
C721 CKXLB1C104YAG
CERAMIC 0
.
1U K
C721 CK1C104KGQBNG
CERAMIC 0
.
1U K
C722 CKXAV1C104EAG
CERAMIC 0
.
1U K
C722 CKXLB1C104YAG
CERAMIC 0
.
1U K
C722 CK1C104KGQBNG
CERAMIC 0
.
1U K
C723 CKXAV1C104EAG
CERAMIC 0
.
1U K

LOCATION C_PARTS_CODE DESCRIPTION
A013 013N5ZW
ELECTRICAL PARTS
EL901 1AV4T40B97800 LCD(T420HW01 V2)
SP901 1LB4A10B10600 SPEAKER
,
8
SP902 1LB4A10B10600 SPEAKER
,
8
SP903 1LB4A10B10500 SPEAKER
,
8
WCN1
-
660 1LB9W0ECM005D
NONSTANDARD WIRE
1LB4J11YA040N SOCKET
,
HOUSING 4P
1LB4J11YA100N SOCKET
,
HOUSING 10P
1LB4J11YA140N SOCKET
,
HOUSING 14P
1LB4J30B0010N TERMINAL
,
SOCKET
8DLO046 CUTTING WIRE
8DLR046 CUTTING WIRE
8DLW058 CUTTING WIRE
8214KG3R0 CUTTING TAPE
WCN2
-
661 1LB9W0CCM003
-
NONSTANDARD WIRE
1LB4J11YA100N SOCKET
,
HOUSING 10P
1LB4J11YA120N SOCKET
,
HOUSING 12P
1LB4J30B0010N TERMINAL
,
SOCKET
8DLR036 CUTTING WIRE
8DLW036 CUTTING WIRE
8214KG3R0 CUTTING TAPE
WSP9C 1LB9W06CM001A
NONSTANDARD WIRE
1LB4J11YA060N SOCKET
,
HOUSING 6P
1LB4J30B0010N TERMINAL
,
SOCKET
8DEW090XM CUTTING WIRE
WSP9L 1LB9W03CM001J
NONSTANDARD WIRE
WSP9R 1LB9W02CM001G
NONSTANDARD WIRE
W1701
-
70 1AA93CN07140X STANDARD WIRE
W1702
-
70 1AA99CM07100X STANDARD WIRE
W662
-
001 1AA95CM01160X STANDARD WIRE
W670
-
101 1AA92CN07160X STANDARD WIRE
W680
-
150 1AA9ECM07260X STANDARD WIRE
W681
-
704 1AA94CN07280X STANDARD WIRE
W7300 1LB4W30B13400 CORD 51PIN (LVDS)
W8001
-
19 1AA94CM07740X STANDARD WIRE
W8002
-
19 1AA97CM07480X STANDARD WIRE
W901 1AV4W10B19100
CORD
,
POWER
-
2
.
23MK
-
A1000 1AA0B10S264B0
ASSY
,
PWB
,
MAIN
+
RC
,
A101 1AA0B10S264BA ASSY
,
PWB
,
MAIN
,
N5ZW
A102 1LB4F1FCX0040 TUNERU/V
C001 CEXLB1V471VEN
ELECT 470U M
C002 CEXLB1V471VEN
ELECT 470U M
C003 CK1H474ZGBFNG
CERAMIC 0
.
47U Z
C004 CK1C105ZGAFNG
CERAMIC 1U Z
C005 CK1C105ZGAFNG
CERAMIC 1U Z
C006 CK1C105ZGAFNG
CERAMIC 1U Z
C007 CK1H474ZGBFNG
CERAMIC 0
.
47U Z
C008 CK1C105ZGAFNG
CERAMIC 1U Z
C009 CEXLB1H471VEN
ELECT 470U M
C010 CK1E224KLZBNG
CERAMIC 0
.
22U K
C011 CEXLB1H100VCG
ELECT 10U M
C011 CE1H100M1WANG
ELECT 10U M
C012 CKXAV1H104EAG CERAMIC0
.
1U K 50V
