Specifications of sensor
Temperature and resistance in temp. sensor (Type: 502AT-1)
Temp.
(㷄)
Resistance
(kȍ)
Temp.
(㷄)
Resistance
(kȍ)
Temp.
(㷄)
Resistance
(kȍ)
Temp.
(㷄)
Resistance
(kȍ)
䋭50
154.5
䋭36
71.80
䋭22
35.65 0 13.29
䋭49
145.9
䋭35
68.15
䋭21
33.99 5 10.80
䋭48
137.8
䋭34
64.71
䋭20
32.43 10 8.84
䋭47
130.2
䋭33
61.48
䋭19
30.92 15 7.20
䋭46
123.1
䋭32
58.43
䋭18
29.50 20 6.01
䋭45
116.5
䋭31
55.55
䋭17
28.14 25 5.00
䋭44
110.2
䋭30
52.84
䋭16
26.87 30 4.17
䋭43
104.4
䋭29
50.23
䋭15
25.65 35 3.50
䋭42
98.87
䋭28
47.77
䋭14
24.51 40 2.96
䋭41
93.70
䋭27
45.45
䋭13
23.42 45 2.51
䋭40
88.85
䋭26
43.26
䋭12
22.39 50 2.13
䋭39
84.18
䋭25
41.19
䋭11
21.41 55 1.82
䋭38
79.80
䋭24
39.24
䋭10
20.48 60 1.56
䋭37
75.67
䋭23
37.39
䋭5
16.43 65 1.35
Temperature and resistance in temp. sensor (Type: PT1000ȍ)
Temp.
(㷄)
Resistance
(kȍ)
Temp.
(㷄)
Resistance
(kȍ)
Temp.
(㷄)
Resistance
(kȍ)
䋭140
450.83
䋭70
729.99 0 1000.0
䋭130
491.47
䋭60
769.02 10 1038.0
䋭120
531.83
䋭50
807.87 20 1076.0
䋭110
571.92
䋭40
846.58 30 1113.8
䋭100
611.76
䋭30
885.13 40 1151.4
䋭90
651.38
䋭20
923.55 50 1189.0
䋭80
690.78
䋭10
961.84 60 1226.4
