Sanyo MDF-U500VX - Temperature Uniformity Testing; Measurement Points for Uniformity

- 50 -
Temperature uniformity data(17 points measured
)
<Measured points>
Top of interior
Lower shelf
Middle shelf
Upper shelf
Bottom of interior
W
H
D
Mullion
Measured points, upper
㽲~㽵: 65mm(H) from top of interior,
27mm(D) and 䇮25.5mm(W) from
each corners on Middle shelf
㽶: 65mm(H) from top of interior
㾁: 10mm(H) from upper shelf
27mmD
65mmH
65mmH
10mmH
25.5mmW
10mmH
10mmH
Measured points, middle
㽷~㽺: 10mm(H), 27mm(D), 25.5mm(W)
䇭䇭䇭䇭䇭from each forner on middle shelf
ĵ: 10mm(H) from middle shelf
Front
Back
㽿
㽾
㽼
㽽
㾀
㽺
㽹
㽷
㽸
㽻
㽵
㽴㽲
㽳
㽶
㾂
㾁
Left Right
Measured points, bottom
㽼~㽿: 65mm(H) from bottom of interior,
28mm(D) and 25.5mm(W) from
each corner on middle shelf
㾀 65mm(H) from bottom of interior
㾂: 10mm(H) from lower shelf
