Sanyo MDF-U5186S - Specifications; Performance

32
SPECIFICATIONS
Name Ultra-Low Temperature Freezer
Model MDF-U2086S
External dimensions W630 x D780 x H1880 (mm)
Internal dimensions W370 x D490x H1200 (mm)
Effective capacity 216 L
Exterior Acrylic finish baked on zinc galvanized steel
Interior Acrylic finish baked on zinc galvanized steel
Door Acrylic finish baked on zinc galvanized steel
Insulation Rigid polyurethane foamed-in place (CFC-FREE)
Compressor Hermetic type, Output; 750 W
Condenser Fin and tube type
Evaporator Tube on sheet type
Refrigerant Mixed refrigerant (CFC-FREE)
Temperature controller Microprocessor control system, 1
o
C graduation (SR485 interface)
Temperature display Digital display (+60 to -180
o
C )
Sensor
Platinum resistance (Pt 1000Ω)
Alarm Buzzer, lamp (filter alarm ; lamp only), Remote alarm contact
Battery For power failure alarm; Nickel-cadmium battery, 6VDC, 270mAh
Shelf 3 shelves
Caster 4 caster
Accessories 1 set of key, 2 rubber caps, 1 scraper
Weight 195 kg
Note: Design or specifications will be subject to change without notice.
The battery for power failure alarm is an article for consumption. It is recommended that the battery will
be replaced about every 3 years. Contact Sanyo sales agency at the time of replacement of the battery
for recycling.
PERFORMANCE
Model MDF-U2086S
Cooling performance Center part of freezing room; -86
o
C (Ambient temperature; +30
o
C, no load)
Control range -20 to -90
o
C
Power source AC 220 V, 50 Hz AC 220 V, 60 Hz AC 230 V, 50 Hz AC 240 V, 50 Hz
Rated power consumption 1150 W 1150 W 1150 W 1150 W
Noise level 50 dB (A scale)
Maximum pressure 2706 kPa
Note: The unit with CE mark complies with EC directives 89/336/EEC, 93/68/EEC and 73/23/EEC.
