7
Safety Instructions
10˚ 10˚
10˚
10˚
Do not tilt the projector more than
10 degrees from side to side.
In upward projection, do
not tilt the projector over
10 degrees right and left.
Do not put the projector on either
side to project an image.
10˚
10˚
In downward projection, do
not tilt the projector over
10 degrees right and left.
Use the projector properly in specified positions. Improper positioning may reduce the lamp life and result in
severe accident or fire hazard.
This projector can project the picture upward, downward, or backward, perpendicular to the plane of the screen
as shown in the figure below.
Bottom
Downward
(Usual)
Front
Downward
Bottom
Upward
Front
Upward
Installing the Projector in Proper Directions
Avoid positioning the projector as described below when installing.
Positioning Precautions
CAUTION
Make sure that the Fan control settings
are set properly when setting up the
projector with upward/downward
inclination of over 20 degrees to the
horizontal plane. Set the Fan control
function in the Setting menu (see page
59).
CAUTION ON CEILING MOUNTING
For ceiling mounting, you need the ceiling mount kit designed for this
porjector. When not mounted properly, the projector may fall, causing
hazards or injury. For details, consult your dealer. The warranty on this
projector does not cover any damage caused by use of any non-
recommened ceiling mount kit or installation of the ceiling mount kit in
an improper location.
