Adjusting the Airflow Direction
I Semi-concealed type
4-way type (X)
This air conditioner is equipped with auto flaps.
You can set the airflow direction to a specific angle or to the sweep
mode using the remote control unit. (Refer to the description of the
remote control unit.)
Do not move the flap with your hands.
I Ceiling mounted type (T)
A. Vertical directions (automatic)
This air conditioner is equipped with an auto flap. You can set the
airflow direction to a specific angle or to the sweep mode using the
remote control unit. (Refer to the description of the remote control unit.)
Do not move the flap with your hands.
B. Horizontal directions (manual)
The horizontal airflow direction can be adjusted manually by moving the
vertical vanes to the left or right.
Auto flap
Vertical vane
