Air outlet
Celling
panel
(optional)
Names of Parts
INDOOR UNIT
SEMI-CONCEALED
X type (4-WAY)
Air outlet Air intake
WALL-MOUNTED
K type
Air intake
Air outlet
CEILING-MOUNTED
T type
Air intake
CONCEALED DUCT
U type
Air outlet
(optional)
Ceiling
Air intake
(optional)
REMOTE CONTROL UNITS
(optional)
(Wired type: (Wireless type:
available for all available for
indoor units) X and T)
This illustration is based on the external
appearance of a standard model.
Consequently, the appearance may differ
from that of the air conditioner you have
selected.
System Remote
Controller
(Wireless type:
available for U)
