Sanyo SAP-KRV9AEH - 4 Refrigerant Flow Diagram

Strainer StrainerCapillary
4. REFRIGERANT FLOW DIAGRAM
4-1. Refrigerant Flow Diagram
Indoor Unit SAP-KRV9AEH
 SAP-KRV12AEH
Outdoor Unit SAP-CRV9AEH
 SAP-CRV12AEH
Compressor
4-way
valve
Accumulator
Wide tube
service
valve
Wide tube
O.D.
9.52 mm
(3/8 ")
Narrow
tube
service
valve
Narrow tube
O.D.
6.35 mm
(1/4")
Heat exchanger
Heat exchanger
Muffler
Cooling cycle
(Defrosting cycle)
Heating cycle
Indoor unit Outdoor unit
15
