9-1-3. Opening and closing of service cover
(1) Remove a service cover mounting screw.
 Lift up the service cover. (Fig.8 and Fig.9)
9-1-4. Removing front grille assembly
(1) Remove the 3 screws, in the right and the left, which fix the main body with the front grille. (Fig.10)
Fig. 8 Fig. 9
Fig. 10
screw
screws
46
