Sanyo SPW-C483GY8 User Manual

SM830052
I-47
ECO MULTI SYSTEM Unit Specifications
1
0123456
0
1
2
3
4
5
HORIZONTAL DISTANCE (m)
AXIS AIR VELOCITY (m/s)
VERTICAL DISTANCE (m)
AXIS AIR VELOCITY
0284_S_I
0123456
0
1
2
3
4
5
HORIZONTAL DISTANCE (m)
AXIS AIR VELOCITY (m/s)
VERTICAL DISTANCE (m)
AXIS AIR VELOCITY
0283_S_I
0123456
0
1
2
3
4
5
HORIZONTAL DISTANCE (m)
AXIS AIR VELOCITY (m/s)
VERTICAL DISTANCE (m)
AXIS AIR VELOCITY
0282_S_I
3-6. Air throw distance chart
Model: 9, 12 Type
3. 2-Way Air Discharge Semi-concealed Type
Model: 18 Type
Model: 25 Type
: LOUVER ANGLE 20˚ in Cooling mode
: LOUVER ANGLE 60˚ in Heating mode
Condition Fan Speed : Hi
Room air temp. : 27 ˚C DB in cooling mode
20 ˚C DB in heating mode

Sanyo SPW-C483GY8 Specifications

General

Refrigerant	R410A
Power Supply	220-240 V, 50 Hz
HSPF	Not available
Type	Split
EER	3.21
Indoor Unit Noise Level	42 dB
Outdoor Unit Noise Level	56 dB(A)
Cooling Capacity	48, 000 BTU/h
