ECO MULTI SYSTEM Unit Specifications
SM830052
I-66
1
6-1. Specifications
Unit specifications (A)
6. Ceiling Mounted Type
MODEL No. Indoor Unit SPW-T183GH56
POWER SOURCE 220 - 230 - 240 V / 1 phase / 50Hz
PERFORMANCE Cooling Heating
Capacity kW 5.6 6.3
BTU / h 19,000 21,000
Air circulation (Hi / Me / Lo) m
3
/ h 900 / 780 / 660
Moisture removal (High) Liters / h 3.0 —
ELECTRICAL RATINGS
Voltage rating V 220 - 230 - 240
Available voltage range V 198 – 264
Running amperes A 0.40 - 0.40 - 0.40 0.30 - 0.30 - 0.31
Power input W 84 - 88 - 93 64 - 68 - 73
Power factor % 95 - 96 - 97 97 - 98 - 98
Fan motor locked rotor amperes A 1 - 1 - 1
FEATURES
Controls / Temperature control Microprocessor / I.C. thermostat
Timer ON / OFF Timer (Max. 72 hr)
Fan speeds (Indoor unit) 3 and Automatic control
Air filter Washable, easy access
Refrigerant control Electronic refrigerant control valve
Operation sound (Hi / Me / Lo) dB-A 42 / 39 / 36
Refrigerant tubing connections Flare type
Refrigerant tube Narrow tube mm (in) 9.52 (3 / 8)
diameter Wide tube mm (in) 15.88 (5 / 8)
Drain connection 20 A, OD26 mm
Remote Controller Optional (RCS-SH80TG)
Refrigerant tubing kit / Accessories Optional / —
DIMENSIONS & WEIGHT Unit dimensions Package dimensions
Dimensions Height mm (in) 185 ( 7 - 1 / 4) 271 ( 10 - 5 / 8)
Width mm (in) 1,073 (42 - 1 / 4) 1,173 ( 46 - 1 / 8)
Depth mm (in) 670 (26 - 3 / 8) 782 ( 30 - 3 / 4)
Net weight kg (lb) 25 ( 55 )
Shipping weight kg (lb) 31 ( 68 )
Shipping volume m
3
(cu. ft) 0.255 ( 9.0 )
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
Rated conditions
Cooling: Indoor air temperature 27 °CDB/19 °C WB, Outdoor air temperature 35 °C DB
Heating: Indoor air temperature 20 °C DB , Outdoor air temperature 7 °CDB/6 °CWB
