2-2-2. Cooling & Electric Heating Type (265 V)
Model Number
STW0633C2 STW0933C2 STW1233C2
STW0634C2 STW0934C2 STW1234C2 STW1534C2
STW1235C2 STW1535C2
Controller PCB
Part No. 851-0-5173-174-00
Controls POW-STW2C3
Compressor
Type Rotary (Hermetic)
Compressor model C-1R45H9Q C-1R65H9R C-R85H9P C-R112H9Y
( Parts code No. ) 80646949-S 80665349-S 80685249-S 80614849-S
Source 265 V 1-phase 60Hz
Nominal output W 450 650 850 1075
Compressor oil ... Amount cc SUNISO 4GSD-T....320 SUNISO 4GSD-T....320 SUNISO 4GSD-T....450 SUNISO 4GSD-T....450
Coil resistance (at 77°F) Ω C-R: 6.32 C-R: 5.66 C-R: 2.785 C-R: 2.274
C-S: 4.46 C-S: 3.12 C-S: 3.076 C-S: 3.478
Safety device Type External protector
Overload relay MRA99059-9201 MRA99140-9201 MRA99134-9201 MRA99038-9201
Operating temp. Open °F
293 ± 9 293 ± 9 293 ± 9 293 ± 9
156 ± 20 156 ± 20 156 ± 20 156 ± 20
Trip in 6 to 16 sec. at 13A Trip in 6 to 16 sec. at 15A Trip in 6 to 16 sec. at 16.5A Trip in 6 to 16 sec. at 24A
Run capacitor 17.5MF, 400VAC 25MF, 400VAC 25MF, 400VAC 25MF, 400VAC
Fan & Fan Motor
Fan type
In Cross-flow (Dia: 3-15/16 / Length: 26-13/16)
Outdoor (Dia./Depth) In Propeller (Dia: 13-15/16 / Depth: 3-15/16)
Fan motor model Indoor / Outdoor UF4S-11A7P-S UE6-41C7P-S UF4S-21C7P-S UE6-41C6P-S
Source 265 V 1-phase 60Hz
Rpm, High Indoor / Outdoor 1,163 1,061 1,427 1,099
Nominal output (W) Indoor / Outdoor 10
Coil resistance (at 68°F) Ω BRN-WHT: 897.7 BRN-WHT: 153.5 BRN-WHT: 361.5 BRN-WHT: 117.4
Indoor / Outdoor WHT-YEL: 217.6 WHT-PNK: 312.9 WHT-YEL: 146.9 WHT-PNK: 221.4
YEL-PNK: 521.8 YEL-PNK: 329.7
Safety device Type Thermal protector
Operating temp. °F
Open: 266 ± 14 Close: 174 ± 27
Run capacitor Indoor / Outdoor 0.6MF, 440VAC 1.0MF, 440VAC 0.8MF, 440VAC 1.5MF, 440VAC
Heat Exch. Coil
Evaporator Coil Aluminum plate fin / Copper tube
Rows 2
Fins per inch 18
Face area
Condenser Coil Aluminum plate fin / Copper tube
Rows 2
Fins per inch 18
Face area
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
