2-2-3. Heat Pump Type (230/208 V)
Model Number
STW0622H2 STW0922H2 STW1222H2 STW1522H2
STW0623H2 STW0923H2 STW1223H2 STW1523H2
STW0925H2 STW1225H2 STW1525H2
Controller PCB
Part No. 851-0-5173-089-00
Controls POW-STW2H
Compressor
Type Rotary (Hermetic)
Compressor model C-1R45H6Q C-1R65H6R C-R85H6P C-R112H6Y
( Parts code No. ) 80646946-S 80665346-S 80685246-S 80614846-S
Source 230-208 V 1-phase 60Hz
Nominal output W 450 650 850 1075
Compressor oil ... Amount cc SUNISO 4GSD-T....320 SUNISO 4GSD-T....320 SUNISO 4GSD-T....450 SUNISO 4GSD-T....450
Coil resistance (at 77°F) Ω C-R: 4.44 C-R: 3.59 C-R: 2.122 C-R: 1.532
C-S: 5.63 C-S: 3.55 C-S: 3.63 C-S: 3.726
Safety device Type External protector
Overload relay MRA99094-9201 MRA99082-9201 MRA99079-9201 MRA99133-9200
Operating temp. Open
°F
302 ± 9 293 ± 9 293 ± 9 320 ± 9
Close °F
156 ± 20 156 ± 20 156 ± 20 156 ± 20
Operating amp. (at 77°F)
Trip in 6 to 16 sec. at 15A Trip in 6 to 16 sec. at 16.5A Trip in 6 to 16 sec. at 20A Trip in 6 to 16 sec. at 26.5A
Run capacitor 17.5MF, 400VAC 25MF, 400VAC 25MF, 400VAC 25MF, 400VAC
Fan & Fan Motor
Fan type
Indoor (Dia./Length)
In Cross-flow (Dia:3-15/16 / Length:26-13/16)
Outdoor (Dia./Depth) In Propeller (Dia: 13-15/16 / Depth: 3-15/16)
Fan motor model Indoor / Outdoor UF4S-11A6P-S UE6-41C6P-S UF4S-21C6P-S UE6-51B6P-S
Source 230-208 V 1-phase 60Hz
Rpm, High (230V) Indoor / Outdoor 1,174 1,065 1,477 1,101
(208V) 1,051 1,021 1,402 1,076
Nominal output (W) Indoor / Outdoor 10
40
20 40
Coil resistance (at 68°F) Ω BRN-WHT: 545.9 BRN-WHT: 117.4 BRN-WHT: 283.6 BRN-WHT: 103.4
Indoor / Outdoor WHT-YEL: 118.1 WHT-PNK: 221.4 WHT-YEL: 101.2 WHT-PNK: 245.5
YEL-PNK: 471.1 YEL-PNK: 259.3
Safety device Type Thermal protector
Operating temp. °F
Open: 266 ± 14 Close: 174 ± 27
Run capacitor Indoor / Outdoor 0.6MF, 440VAC 1.5MF, 440VAC 1.0MF, 440VAC 1.5MF, 440VAC
Heat Exch. Coil
Evaporator Coil Aluminum plate fin / Copper tube
Rows 2
Fins per inch 18
Face area
ft
2
1.87
Condenser Coil Aluminum plate fin / Copper tube
Rows 2
Fins per inch 18
Face area
ft
2
2.45
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
