Pan and Tilt Settings (PAN/TILT)
Pan and tilt settings such as camera’s orientation can be registered
as preset positions. Preset positions can be grouped and individual
preset position groups can be used for Sequence mode.
Selecting a preset number displays the screen for selecting preset
options.
Selecting [CAMERA VIEW] displays the CAMERA VIEW screen used
for configuring the camera view setting file.
You can make the amount of movement in the screen constant by
changing the moving speed of the camera during manual operation
according to the zoom magnification power.
The still image can be used in the screen while switching to other
preset position.
You can set the starting point (0 degrees) angle for the camera by
orienting it to your desired direction and saving the direction
information.
You can limit the tilting angle of the camera to your desired value.
CAMERA y
LENS y
PAN/TILT y
AUTO MODE y
ALARM y
PRIVACY MASK y
PASSWORD y
LANGUAGE y
OPTION y
PRESET
MENU
PAN/TILT SETTING
PRESET POSITION y
PROPORTIONAL
FREEZE
SET NORTH y
TILT LIMIT
PRESET
MENU
A
B
E
D
C
SET
SET
SET
SET
SET
SET
SET
SET
SET
OFF
BACK
SET
ON
OFF
OFF
6
OFF
BACK
A
Registering a surveillance location (PRESET
POSITION)
PRESET NO.SELECT
1:A 11:- 21:- 31:-
2:- 12:- 22:- 32:-
3:- 13:- 23:- 33:-
4:- 14:- 24:- 34:-
5:- 15:- 25:- 35:-
6:- 16:- 26:- 36:-
7:- 17:- 27:- 37:-
8:- 18:- 28:- 38:-
9:- 19:- 29:- 39:-
10:- 20:- 30:- 40:-
MENU
BACK
☞P26
(Preset map screen)
PRESET NO.001
POSITION y
TITLE y
CAMERA VIEW y
HOLD
SEQUENCE
GROUP
PAUSE TIME
PRESET GO y
MENU
SET
OFF
OFF
OFF
A
5S
SET
BACK
☞P26
(Preset setting screen)
CAMERA VIEW 1
MOTION
IRIS y
WHITE BALANCE y
BLC
SHUTTER
APERTURE y
AGC y
GAMMA
DAY/NIGHT y
PRESET
MENU
OFF
AUTO
ATW
OFF
OFF
ON
ON
0.45
AUTO
OFF
BACK
(CAMERA VIEW screen)
☞P27
B
Making the amount of movement in the screen
constant (PROPORTIONAL)
C
Displaying a still image while switching the
surveillance location (FREEZE)
D
Setting the starting point (0 degrees) angle
information (SET NORTH)
E
Limiting the tilting angle (TILT LIMIT)
PAN/TILT SETTING
PRESET POSITION y
PROPORTIONAL
FREEZE
SET NORTH
TILT LIMIT
SET
ON
OFF
OFF
6
☞P31
y
PAN/TILT SETTING
PRESET POSITION
PROPORTIONAL
FREEZE
SET NORTH
TILT LIMIT
SET
ON
ON
OFF
6
☞P31
y
y
PAN/TILT SETTING
PRESET POSITION
PROPORTIONAL
FREEZE
SET NORTH
TILT LIMIT
SET
ON
OFF
SET
6
☞P31
y
PAN/TILT SETTING
PRESET POSITION
PROPORTIONAL
FREEZE
SET NORTH
TILT LIMIT
SET
ON
OFF
OFF
6
☞P32
