Alarm Settings (ALARM)
43
Set the alarm output options for the alarm detection in the
surveillance area (AREA 1 - 4).
After returning to the MOTION ZONE screen, perform the following
procedure.
1
Use the joystick lever (xy) to select [ALARM OUT]
and use the lever (vw) to select an alarm output
terminal.
Available settings:
•OFF: Does not output the alarm signal.
•1: Uses the output terminal 1.
•2: Uses the output terminal 2.
2
Use the joystick lever (xy) to select [LINE OUT] and
use the lever (vw) to determine whether the alarm
signal is output to the connection line with the
system controller.
Available settings:
•OFF: Does not output the alarm signal to the connection
line.
•ON: Outputs the alarm signal to the connection line.
3
Use the joystick lever (xy) to select [DURATION]
and use the lever (vw) to select the interval after
which the next alarm becomes in effect.
Available settings: 5S, 10S, 15S, 20S, 30S, 45S, 1M, 2M,
3M, 4M, 5M (S: Second, M: Minute)
☞ After completing setting, use the lever to move the cursor to
[MENU] and select “BACK” or “END”.
When the alarm is detected, the preset number and the camera ID on
the screen flash notifying that the alarm is detected.
Monitor display legend
1
Use the joystick lever (xy) to select [ALARM
DISPLAY] and use the lever (vw) to select
“ON/OFF”.
Available settings:
•OFF: The alarm information does not flash.
•ON: The alarm information flashes.
([TIME] appears under [ALARM DISPLAY].)
2
When “ON” is selected, use the joystick lever (xy)
to select [TIME], and use the lever (vw) to select the
duration for which the alarm information is
flashing.
Available settings: 5S, 10S, 15S, 20S, 30S, 45S, 1M, 2M,
3M, 4M, 5M (S: Second, M: Minute)
☞ After completing setting, use the lever to move the cursor to
[MENU] and select “BACK” or “END”.
Setting the alarm signal output
MOTION ZONE
AREA 1
AREA 2
AREA 3
AREA 4
SENSITIVITY y
ALARM OUT
LINE OUT
DURATION
PRESET
MENU
OFF
OFF
OFF
OFF
SET
OFF
OFF
5S
OFF
BACK
E
Setting the alarm information display
(ALARM DISPLAY)
ALARM
ALARM IN y
ALARM OUT y
ALARM DISABLE
TIME
MOTION
ALARM DISPLAY
TIME
PRESET
MENU
001 CAM1 FLOOR
1
1
ON
1M
PRESET
ON
5S
OFF
BACK
