22
Note:
1. Materials of Capacitors and Resistors are abbreviated as follows ;
Resistors Capacitors
MT-FILM Metallized Film Resistor MT-POLYEST Metallized Polyester Capacitor
MT-GLAZE Metallized Glaze Resistor MT-COMPO Metallized Composite Capacitor
OXIDE-MT Oxide Metallized Film Resistor TA-SOLID Tantalum Solid Capacitor
AL-SOLID Aluminum Solid Capacitor
NP-ELECT Non-Polarized Electrolytic Capacitor
OS-SOLID Aluminum Solid Capacitors with Organic
Semiconductive Electrolytic Capacitor
DL-ELECT Double Layered Electrolytic Capacitor
2. Tolerance of Capacitor (10pF over) and Resistor are noted with follow symboles.
F ............1% G ............2% J ............5% K ............10%
M ..........20% N ..........30% Z ..........+80% ~ -20%
3. Capacitors
U :
µ
FP : pF
4. Inductors
UH :
µ
H MH : mH
5. N.S.P. : Not available as service parts.
LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION
ELECTRICAL PARTS
COMPL PWB,CP-1
636 072 8271
(VARISTORS)
VA131 408 050 0504 VARISTOR AVR-M1005C080MT
VA132 408 050 0504 VARISTOR AVR-M1005C080MT
(SEMICONDUCTORS)
Q1304 405 168 3700 TR DTC144EM
Q1305 405 167 0304 TR EMD3
Q1306 405 166 9506 TR EMH2
Q1431 405 168 3700 TR DTC144EM
Q1432 405 167 7303 TR UMD12N
Q1501 405 166 9605 TR EMT1
Q1502 405 168 3908 TR EMZ1
Q1503 405 102 6705 TR 2SA1745-7
OR 405 102 8303 TR 2SA1745-6
Q1504 405 168 3700 TR DTC144EM
Q1701 405 173 3009 TR 12A01SS
Q1702 405 168 3700 TR DTC144EM
Q3001 405 168 4004 TR DTA114EM
Q3002 405 115 6709 TR DTC123EE
Q3003 405 168 3809 TR DTA144EM
Q3004 405 168 3700 TR DTC144EM
Q9301 405 102 5609 TR 2SD1819A-R
OR 405 092 4101 TR 2SC4081-R
Q9302 405 102 5609 TR 2SD1819A-R
OR 405 092 4101 TR 2SC4081-R
Q9510 405 092 2107 TR 2SC4097-R
Q9511 405 168 9504 TR DTC115EM
Q9512 405 148 7100 TR CPH6401
Q9513 405 168 9504 TR DTC115EM
(INTEGRATED CIRCUITS)
IC101 410 472 1502 IC KS6U2U1715CBP (N.S.P.)
IC103 409 541 5107 IC K4S283233F-MN1L (N.S.P.)
IC105 409 479 6009 IC TC7MH273FK
IC106 409 479 6009 IC TC7MH273FK
IC111 409 540 3708 IC BU2389KN-E2
IC121 409 572 7507 IC 64900712C
IC151 409 528 6301 IC TK15465STB
IC172 409 446 9309 IC NJM2125F
IC301 410 499 3008 IC UPD780023AGB-G30-8EU
OR 410 492 1506 IC UPD78F0034AGB-G30-8EU
IC302 409 530 6900 IC S-8424BAAFT
IC931 409 529 5808 IC AD9847AKST
IC932 409 505 9400 IC TK11130CS
IC934 409 446 8708 IC CXD3400N
IC935 409 446 8708 IC CXD3400N
IC951 409 512 9806 IC LB8649FN
IC954 409 526 4002 IC XC9104D095M
(DIODES)
D1001 407 210 1900 DIODE 1SS400
D1501 407 109 4609 DIODE MA728
D1701 407 221 4105 DIODE MA2SD19
D1901 407 210 1900 DIODE 1SS400
D3001 407 205 2806 DIODE RB520S-30
D3002 407 229 9409 LED SML-311DT
D3003 407 229 9409 LED SML-311DT
D3004 407 229 9409 LED SML-311DT
D3005 407 222 4807 LED SML-521MUW
D3010 407 227 3102 DIODE EMP11
D3011 407 227 3102 DIODE EMP11
D3012 407 227 3102 DIODE EMP11
D3013 407 227 3102 DIODE EMP11
D9301 407 198 9905 DIODE MA727
D9302 407 113 5609 DIODE DSH015
OR 407 134 7200 DIODE MA141K
OR 407 220 7305 DIODE MA142K-G
OR 407 153 7205 DIODE MA142K
D9501 407 201 2701 DIODE RB051L-40
(OSCILLATORS)
X1101 645 053 8780 OSC,CRYSTAL 28.63636MHZ
X3001 645 046 1415 OSC,CERAMIC 4.00MHZ
X3002 645 054 3791 OSC,CRYSTAL 32.768KHZ
(FILTERS)
XF101 645 057 0551 FILTER,EMI 1000000PF
XF111 645 057 0551 FILTER,EMI 1000000PF
XF931 645 057 0551 FILTER,EMI 1000000PF
(INDUCTORS)
L1001 645 020 1912 INDUCTOR,240 OHM
L1040 645 037 1523 INDUCTOR,10U K
L1051 645 037 1530 INDUCTOR,47U K
L1101 645 020 1912 INDUCTOR,240 OHM
L1103 645 020 1899 INDUCTOR,68 OHM
L1301 645 037 4340 INDUCTOR,1000 OHM
L1302 645 037 4340 INDUCTOR,1000 OHM
L1303 645 037 4340 INDUCTOR,1000 OHM
L1501 645 035 7190 INDUCTOR,33U J
L1701 645 037 1523 INDUCTOR,10U K
L1702 645 037 1523 INDUCTOR,10U K
L1703 645 037 1523 INDUCTOR,10U K
L1704 645 037 1523 INDUCTOR,10U K
L1705 645 053 8872 INDUCTOR,100U K
L1901 645 041 1977 INDUCTOR,330 OHM
L1902 645 041 1977 INDUCTOR,330 OHM
L9301 645 020 1912 INDUCTOR,240 OHM
L9302 645 053 8872 INDUCTOR,100U K
L9303 645 020 1882 INDUCTOR,1800 OHM
L9501 645 058 0918 INDUCTOR,10U M
(CAPACITORS)
C1026 403 312 6805 CERAMIC 0.1U Z 16V
C1028 403 312 6805 CERAMIC 0.1U Z 16V
C1030 403 312 6805 CERAMIC 0.1U Z 16V
C1032 403 312 6805 CERAMIC 0.1U Z 16V
C1034 403 312 6805 CERAMIC 0.1U Z 16V
C1037 403 312 6805 CERAMIC 0.1U Z 16V
C1039 403 312 6805 CERAMIC 0.1U Z 16V
To Next Page
