Note:
1. Materials of Capacitors and Resistors are abbreviated as follows ;
Resistors Capacitors
MT-FILM Metallized Film Resistor MT-POLYEST Metallized Polyester Capacitor
MT-GLAZE Metallized Glaze Resistor MT-COMPO Metallized Composite Capacitor
OXIDE-MT Oxide Metallized Film Resistor TA-SOLD Tantalum Solid Capacitor
AL-SOLID Aluminum Solid Capacitor
NP-ELECT Non-Polarized Electrolytic Capacitor
OS-SOLID Aluminum Solid Capacitors with Organic
Semiconductive Electrolytic Capacitor
DL-ELECT Double Layered Electrolytic Capacitor
2. Tolerance of Capacitor (10pF over) and Resistor are noted with follow symboles.
F ............1% G ............2% J ............5% K ............10%
M ..........20% N ..........30% Z ..........+80% ~ -20%
3. Capacitors
U :
µ
FP : pF
4. Inductors
UH :
µ
H MH : mH
5. N.S.P. : Not available as service parts.
LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION
ELECTRICAL PARTS
COMPL PWB,CA-1
636 064 1778
(SEMICONDUCTORS)
Q9001 405 102 5609 TR 2SD1819A-R
OR 405 092 4101 TR 2SC4081-R
Q9002 405 153 6709 TR 2SC3931-D
(INTEGRATED CIRCUITS)
IC901 409 446 8708 IC CXD3400N
IC902 409 446 8708 IC CXD3400N
(DIODES)
D9001 407 113 5609 DIODE DSH015
OR 407 134 7200 DIODE MA141K
D9002 407 198 9905 DIODE MA727
D9003 407 222 4807 LED SML-521MUW
D9004 407 205 2707 LED SML-310LT
D9005 407 198 9905 DIODE MA727
(CAPACITORS)
C9001 403 320 5500 CERAMIC 1U Z 25V
C9002 403 312 6805 CERAMIC 0.1U Z 16V
C9003 403 283 6309 CERAMIC 1U Z 10V
C9004 403 311 7605 CERAMIC 2200P K 50V
C9005 403 283 6309 CERAMIC 1U Z 10V
C9006 403 283 6309 CERAMIC 1U Z 10V
C9007 403 311 3409 CERAMIC 0.01U K 16V
C9008 403 311 3409 CERAMIC 0.01U K 16V
C9009 403 312 6805 CERAMIC 0.1U Z 16V
C9010 403 320 5500 CERAMIC 1U Z 25V
C9011 403 312 6805 CERAMIC 0.1U Z 16V
C9012 403 312 6805 CERAMIC 0.1U Z 16V
C9013 403 312 6805 CERAMIC 0.1U Z 16V
C9014 403 312 6805 CERAMIC 0.1U Z 16V
C9015 403 283 6309 CERAMIC 1U Z 10V
C9016 403 283 6309 CERAMIC 1U Z 10V
C9017 403 332 8209 CERAMIC 10U M 16V
C9018 403 312 6805 CERAMIC 0.1U Z 16V
C9019 403 312 6805 CERAMIC 0.1U Z 16V
C9020 403 332 8209 CERAMIC 10U M 16V
C9021 403 332 8209 CERAMIC 10U M 16V
C9022 403 320 5500 CERAMIC 1U Z 25V
C9023 403 312 6805 CERAMIC 0.1U Z 16V
(RESISTORS)
R9001 401 224 8900 MT-GLAZE 100K JA 1/16W
R9002 401 261 5900 MT-FILM 330 DU 1/16W
R9003 401 261 3906 MT-FILM 2.2K DU 1/16W
R9004 401 225 7902 MT-GLAZE 220 JA 1/16W
R9005 401 225 7902 MT-GLAZE 220 JA 1/16W
R9006 401 225 7902 MT-GLAZE 220 JA 1/16W
R9007 401 225 7902 MT-GLAZE 220 JA 1/16W
R9008 401 225 7902 MT-GLAZE 220 JA 1/16W
R9009 401 225 7902 MT-GLAZE 220 JA 1/16W
R9010 401 225 7902 MT-GLAZE 220 JA 1/16W
R9011 401 225 7902 MT-GLAZE 220 JA 1/16W
R9012 401 224 9402 MT-GLAZE 1.0M JA 1/16W
R9013 401 224 9006 MT-GLAZE 10K JA 1/16W
R9014 401 240 9004 MT-GLAZE 3.9 JA 1/16W
R9015 401 225 0903 MT-GLAZE 82K JA 1/16W
R9016 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R9017 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R9018 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R9019 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R9020 401 224 8801 MT-GLAZE 100 JA 1/16W
R9021 401 225 0200 MT-GLAZE 3.3K JA 1/16W
R9023 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R9024 401 263 2303 MT-GLAZE 750 JA 1/16W
(MISCELLANEOUS)
636 064 8180 SPACER,CA1-SX511
(CONNECTORS)
CN901 645 045 4424 SOCKET,26P (N.S.P)
CN902 645 027 5340 PLUG,3P (N.S.P)
COMPL PWB,CA-2
636 064 1761
(SEMICONDUCTORS)
Q1011 405 115 7201 TR DTC144EE
Q1012 405 129 3107 TR UMD3N
Q1013 405 115 7201 TR DTC144EE
Q1015 405 115 5702 TR DTA144EE
Q1041 405 115 7201 TR DTC144EE
Q1301 405 129 2001 TR UMH2N
Q1421 405 115 5702 TR DTA144EE
Q1422 405 115 7201 TR DTC144EE
Q1501 405 129 2100 TR UMT1N
Q1502 405 129 2308 TR UMZ1N
OR 405 106 4806 TR XP4601
Q1503 405 129 2308 TR UMZ1N
OR 405 106 4806 TR XP4601
Q1507 405 102 6705 TR 2SA1745-7
OR 405 102 8303 TR 2SA1745-6
Q1508 405 115 7201 TR DTC144EE
Q1601 405 115 6907 TR DTC114EE
Q1602 405 102 6705 TR 2SA1745-7
OR 405 102 8303 TR 2SA1745-6
Q1621 405 102 5609 TR 2SD1819A-R
OR 405 092 4101 TR 2SC4081-R
Q1622 405 115 5702 TR DTA144EE
Q1623 405 129 2209 TR UMX1N
OR 405 106 4707 TR XP4501
Q9101 405 115 7201 TR DTC144EE
Q9103 405 102 5609 TR 2SD1819A-R
OR 405 092 4101 TR 2SC4081-R
(INTEGRATED CIRCUITS)
IC102 410 415 1507 IC LC98600BF-UH6 (N.S.P)
IC106 409 502 3807 IC HY57V641620HGT-H
OR 409 522 9407 IC K4S641632F-TC75
IC107 409 502 3807 IC HY57V641620HGT-H
OR 409 522 9407 IC K4S641632F-TC75
IC111 409 486 8201 IC IMIC6002AT
IC121 409 530 5903 IC 60600215H
IC138 409 327 6502 IC TC7W32FU
IC139 409 149 5301 IC TC7S00F
IC146 409 471 4201 IC SN74LV245ADB
