Specications
Power Supply • 18V 1.5A Power Supply
• 12-24V DC 2A External Supply
Controls • Rotary Volume Control
• Rotary Tone control
• On/O power switch
• Source selector switches
• Priority switch
Input connections • Digital Audio TOSlink/Coaxial
• 2 x Microphone inputs. 3.5mm mono jack plug. DC powered 5V
for electret microphones
• 2x Aux In Left/Right line inputs. Phono/RCA sockets. For direct
connection to a TV sound output or other audio source via SCART
or other suitable socket.
Output connections • Push grip connectors for loop cable or loop pad (Labelled: Loop
Cable). Loop will give full output with loop resistance between 0.5
and 1.5 Ohms.
• 3.5mm stereo jack for headphones (Phones) 8-60 Ohms
Loop output • 3.0A output current @ 100-5KHz. Meets BS EN60118-4:2006 for
a loop not exceeding 6.5m (20ft) in width . Suitable for areas up
to 70m
2
Loop cable • Single turn loop cable. System supplied with 40m (130ft)
24/0.2mm (0.75mm
2
) single core PVC insulated cable. Min cable
length 11m = 0.5 Ohms
Indicators • Blue/Red LEDs
Sarabec Ltd declares that the LA240 complies with all relevant EU directives. The
full EU declaration of conformance for the LA240 is available from Sarabec Ltd.
