IN220 Cylindrical Lock
The lock is shipped “preset” and does not require adjustment for 1-3/4” thick doors.
5
Lock Adjustments
NOTE: Adjusting for a thicker door requires removal of the outside lever, scalp and
spacer bushing; see following sections.
If preset lock does not require adjustment, proceed to Step 7 - Install Lock
A. Lock Preset:
• Lock body holes: 12 and 6 o’clock (Fig. 5).
Outside of Door
Fig. 5
Door thickness:
1-3/4” thick
To Next Page
