IN220 Cylindrical Lock
13
Inside Cover Installation
Inside
Cover
Security Allen
Screw
Fig. 13
1. Assemble cover by hooking top edge on inside
mounting plate.
2. Carefully press bottom of cover toward door without
pinching any wires.
3. Secure cover utilizing security allen wrench.
To Next Page
