24
Specifications
Model B 3100S B 4100 B 6100
Capacity/weighing range g 3,100 4,100 6,100
Readability g 0.01 0.1 0.1
Tare range (by subtraction) g -3,100 -4,100 -6,100
Standard deviation g
≤
±0.01
≤
±0.05
≤
±0.05
Max. linearity g
≤
±0.02
≤
±0.1
≤
±0.1
Stabilization time (typical) s 2 1.5 1.5
Display update s 0.1 – 0.8 (selectable)
Adaption to ambient conditions
and application requirements
by selection of one of 4 optimized filter levels
Stability range d 0.25 ... 64 (selectable)
Ambient temperature range K 273 – 313 (0
o
C ... +40
o
C)
Allowable relative humidity 15 … 85
(moisture-proof rating)
Sensitivity drift within
+10 … +30
o
C
/
o
C
≤
±2∙10
-6
≤
±5∙10
-6
≤
±5∙10
-6
Pan size
mm
in.
235 x 180
9.3 x 7.1
Balance housing (W x D x H)
mm
in.
250 x 270 x 65
9.8 x 10.6 x 2.6
Net weight kg/lbs. 5/11 3.5/7.7 3.5/7.7
Power requirements
(voltage + frequency)
115 or 230 V depending on the AC adapter used
50 – 60 Hz
Allowable voltage fluctuation -20% … +15%
Power consumption(typical) VA max. 7.5 7.5 7.5
Interface (optional)
RS 232 C/V24 – 28, RS 423/V10; 7-bit;
parity: even, mark, odd, space;
transmissions rate: 150 ... 9,600 Baud
