6 |
Models with Special Weighing Systems
Weighing systems - Strain gauge on low-resolution balances/scales,
Double lever system and forked lever system on high resolution precision balances
Monolithic weigh cells on analytical balances
Span adjustment - With external weights on precision balances not verifi ed for legal metrology
- With built-in weights on analytical balances and precision balances verifi ed for
legal metrology
Linearity - Is internally possible using (2 built-in weights) on analytical balances,
- On other models with external service software (CAS, PC/ PSION)
Menu locking - Menu access can be blocked by entering code (8-1-2) of the balance/scale
operating program
- The access lock switch is only functional on calibration models (calibration/
adjustment externally blocked)
BPI switch - (BPI = Binary Processor Interface) to prepare for working with CAS service
software, log out with „CLOSE“ function
- Or if all else fails by resetting the operating menu (9-1°)
Be careful, the factory settings are activated.
ERR 30 is also shown after pressing the p key, if the wrong interface cable
is used!
Models with Special Weighing Systems
Model 1
Weighing system: Strain gauge
(Strain gauge) (see right)
CP622
Model 2
Weighing system:
Strain gauge (see right)
CP8201, CP6201, CP4201, CP2201,
GP8201
Weighing system:
Angled lever (see below, right)
CP4202S, CP3202S, CP3202P,
CP2202S, GP5202, GP3202
CP_01b.eps
CP_01b.eps
CP_01.eps
