Sartorius ED2202S-0CE User Manual

Model ED6202S | ED4202S | ED3202S | ED2202S | ED822 |
GW6202 | ED4202S GW3202 | ED2202S ED822
ED6202S-CW -CW ED3202S-CW -CW -CW
Weighing capacity g 6200 4200 3200 2200 820
Readability g 0.01 0.01 0.01 0.01 0.01
Tare range (subtractive) g 6200 4200 3200 2200 820
Repeatability (std. deviation) <±g 0.01 0.01 0.01 0.01 0.01
Linearity <±g 0.02 0.02 0.02 0.02 0.02
Stabilization time (typical) s 1.1 1.1 1.1 1.1 1.0
Sensitivity drift within <±/K 2 · 10
–6
2 · 10
–6
2 · 10
–6
2 · 10
–6
5 · 10
–6
+10 to +30°C
Adaptation to ambient By selection of 1 of 4 optimized filter levels;
conditions display update: 0.05–0.4 s (depends on filter level selected)
External calibration weight
(of at least accuracy class...) g 5000 (E2) 2000 (E2) 2000 (F1) 2000 (F1) 500 (F2)
Net weight, approx: kg 33.1|3.1|3.5 3.1|3.5 3.1|3.1|3.5 3.1|3.5 2|2.6
Weighing pan size mm 180 + 180 180 + 180 180 + 180 180 + 180 150 d
Dimensions (W + D + H) mm 230 + 303 + 91 230+303+87
Model ED8201 | GW7201 ED5201 | ED2201 |
ED8201-CW ED5201-CW ED2201-CW
Weighing capacity g 8200 7200 5200 2200
Readability g 0.1 0.1 0.1 0.1
Tare range (subtractive) g 8200 7200 5200 2200
Repeatability (std. deviation) <±g 0.1|0.3 0.1|0.3 0.1|0.3 0.1|0.3
Linearity <±g 0.1|0.3 0.1|0.3 0.1|0.3 0.1|0.3
Response time (average) s 1 1 1 1
Sensitivity drift within <±/K 10 · 10
–6
+10 to +30°C
Adaptation to ambient By selection of 1 of 4 optimized filter levels;
conditions display update: 0.05–0.4 s (depends on filter level selected)
External calibration weight
(of at least accuracy class...) g 5000 (F2) 5000 (F2) 5000 (F2) 2000 (F2)
Net weight, approx.: kg 2.7 | 3.5 2.7 2.7 | 3.5 2.7 | 3.5
Weighing pan size mm 180 + 180
Dimensions (W + D + H) mm 230 + 303 + 91
53

Sartorius ED2202S-0CE Specifications

General

Brand	Sartorius
Model	ED2202S-0CE
Category	Scales
Language	English
