21
Interface Port
Data Interface Pin Assignment
9-contact interface port
Pin 2: (RXD) Receive Data
Pin 3: (TXD) Transmit Data
Pin 4: (DTR) Data Terminal Ready
Pin 5: (GND) Ground
Pin 6: BPI bridge
Pin 8: (CTS) Clear to Send
Specifications
Model PMA 7501| PMA7501-000W
Weighing range g 999.95/7500
Readability g 0.05/0.1
Tare range (subtractive) g -999.95/-7500
Max. linearity g < ±0.2
Stabilization time (average) digit 0.25 to 4
Moisture-proof rating F Non-condensing
Allowable ambient operating
temperature range °C 0 to +40
Weighing pan d mm 233
Scale housing (W + D + H) mm 233 + 329 + 391
Net weight, approx. kg 3.3
Calibration weight kg 5, class F2 or better
Power consumption VA Average: 8; maximum: 16
Interface RS-232C
– Format 7-bit ASCII, 1 start bit,1 or 2 stop bits
– Parity Even, odd or no parity
– Transmission rates 1200 to 38,400 bit/s
– Handshake mode Software or hardware
