Operating Instructions SATA lter 500
Operating Instructions SATA lter 500
4. Technical Design of the Filters [1]
[1-1] Air inlet G ½" (internal
thread)
[1-2] Air outlet G ½“ (female
thread)
[1-3] Ball valves with air outlet ¼“
(male thread)
[1-4] CO monitor connector G ¼“
(female thread)
[1-5] SATA lter timer 6 months
[1-6] Pressure gauge 0 - 15 bar
[1-7] Pressure control valve (not
visible)
[1-8] Regulation knob
[1-9] Filter housing, lter stage A
[1-10] Integrated automatic con-
densate drain valve
[1-11] Filter housing, lter stage B
[1-12] Filter housing, lter stage C
[1-13] Mounting bracket
[1-14] Condensate outlet hose (not
visible)
[1-15] Filter head
[1-16] Special seal (not visible)
5. Intended Use
The SATA 󰘰lters 500 have been developed to purify technical com-
pressed air. They separate solid, liquid and partly gaseous particles from
the compressed air 󰘱owing through the 󰘰lter.
6. Safety Instructions
6.1. General Safety Instructions
Warning! Attention!
• Before using the lters, please read the safety and operating instruc-
tions completely and carefully. Safety instructions and specied steps
are mandatory.
• Keep all the enclosed documents and always only pass on the lter
together with these documents.
