Operating Instructions SATA lter 500
Notice!
Activated charcoal filter cartridge:
• Sintered activated charcoal
9.4. Pressure reducer unit [D]:
The standard pressure reducer unit is equipped with 2 ball valves [1-3]
connecting thread ¼" (male thread) and can be extended with an outlet
module. The required outlet pressure can be nely adjusted at the pres-
sure reducing valve [1-7] using the regulating cap [1-8] and pressure
gauge [1-6].
10. Maintenance
Warning! Attention!
• Filters can only be maintained and serviced when depressurised!
• Sintered lter [A]/Art. No. 22160, lter housings [1-9], [1-11],
[1-12] and special seal [1-16] must be cleaned at the latest after 6
months; replace sintered lter if necessary!
• Replace the ne lter cartridge [B]/Art. No. 1097999 at the latest
after 6 months!
• Replace the activated charcoal cartridge [C]/Art. No. 1098004 at
the latest after 6 months!
• When the compressed air is heavily contaminated, the filter
cartridges have to be exchanged in shorter intervals!
• Saturated filter cartridges may cause malfunctions during paint
jobs. Furthermore, the use of air-fed breathing protection equip-
ment could be harmful, causing permanent health damage and
even death!
• Always make sure that the filter housings are fitted correct-
ly! Filter housings are only correctly tted after an audible “click”!
Notice!
Please observe local regulations for the disposal of lter cartridges!
