Operating Instructions SATA lter 500
Operating Instructions SATA lter 500
Notice!
Mount shut-o tap in front of the lter, e.g. Art. No. 10934 (not includ-
ed in delivery), allowing easy and safe lter maintenance.
7.2. Retrofit SATA filter 544 to SATA filter 584
A SATA lter 564 [C ](Art. No. 1101005) is needed for retrotting with an
activated charcoal lter:
1. Depressurise lter (close shut-o tap)
2. Remove lter housings [3-1] by turning clockwise
3. Take out the lter cartridges [3-2], check and clean or replace if nec-
essary
4. Take SATA lter 544 from the wall
5. Remove screws [3-3] (Caution! Filter heads [1-15] loose)
6. Remove 3-stage wall-mounting kit [3-4]
7. Pull o the pressure reducer [D] [3-5]
8. Attach lter bodies [3-6] (Caution! Heed installation position!)
9. Insert connecting sleeve [3-7]
10. Attach pressure reducer [3-8] and slide lter stages onto block
11. Hold 4-stage wall-mounting kit [3-9] in position and fasten with screws
[3-10]
12. Firmly fasten SATA lter 584 to wall in a horizontal position, using the
existing holes
13. Insert lter cartridges [3-11] in lter housings [3-12] and mount on
the lters (Caution! Filter housings are only correctly tted after an
audible “click”!), and attach the new SATA lter timer [1-5] and press
to activate
14. Slowly open upstream shut-o tap (not included in delivery)
7.3. Change air flow for SATA filter 584 from right
to left
1. Depressurise lter (close shut-o tap)
2. Remove lter housings [4-1] by turning clockwise
3. Loosen cover unit screws and remove unit [4-2]
4. Loosen screws of wall-mounting kit and remove wall-mounting kit [4-
3]
(Caution! Filter heads [1-15] loose)
5. Loosen and remove [4-4] dummy plug
