9 / 37
So that the EME Guard can be « worn » it is equipped with a two-part clip belt; a belt clip
which slides onto a stud situated on the back of the device.
Slide the stud horizontally into the
groove.
Pivot the dosimeter downwards.
The connectors for the battery charger and the USB are situated on the base of the
dosimeter, protected by a lid.
The following procedure must be followed when opening the lid.
To open the lid:
apply pressure to
the hinge…
…and lift the lid
Figure 3 : The EME Guard Dosimeter seen from below
Battery charger
connector
USB connector
