ENGLISH - 10
Incorrect setting causes deterioration of reception performance.
※
HOME position is when the antenna completely folded down and facing backward.
※
5. Functional description
5-1. Get ready to use
c. HOME LED and a satellite, either the default satellite “VAST” or the last selected
satellite, will be solid this means the antenna is ready to go.
(If the antenna is not at HOME, HOME LED ashes while moving to HOME position)
The ORBIT can still locate the satellite without the GPS locked.
※
d. GPS LED ashes while searching for the current location. When GPS position is
conrmed the LED will become solid.
e. Waiting until both HOME & GPS LEDs are solid is recommended as this will allow the
unit to nd the selected satellite faster with more precise alignment accuracy.
a.
b.
When the all cable connections are completed, press Power button.
All satellite LEDs will ash and then system is displayed like below image.
See below the controller has correct pre-setting.
Do not change setting unless mismatch with below example.
Auto skew
#1,4 down
1
↓
↑
234
Controller Back
Auto skew function On(●) / O(○)
STB Power Detection On(●) / O(○)
Dish type : 85cm(●)
Software version (Binary code)
To Next Page
