Fasten the UPRIGHT (C3) to the DESK TOP (D3)
and BOTTOM (F3). Use four BLACK 1-15/16" FLAT
HEAD SCREW (113S).
Step 3
411606www.sauder.com/service
Page 7
C3
F3
Surface without HIDDEN CAMS
Unfi nished
surface
Do not stand the unit upright without the
BACK fastened. The unit may collapse.
Caution
BLACK 1-15/16" FLAT HEAD SCREW
(4 used in this step)
113S
D3
Curved edge
Unfi nished edge
Surface with holes
To Next Page
