Step 11
416407www.sauder.com/service
Page 15
å
Turn the drawer over and fasten the DRAWER BRACE (M67) to
the DRAWER FRONT (H). Tighten a HIDDEN CAM.
å
Fasten the DRAWER BRACE (M67) to the DRAWER BACK (D175).
Use a BLACK 1-9/16" FLAT HEAD SCREW (30S).
å
Repeat this step for the other drawers.
Arrow
Minimum
190 degrees
Maximum
210 degrees
H
Surface with
HIDDEN CAM
D175
BLACK 1-9/16" FLAT HEAD SCREW
(4 used in this step)
30S
M67
Hidden part using
recycled material.
Color may vary.
