Step 4
416407 www.sauder.com/servicePage 8
å
Fasten the LEFT END (B2) to the TOP (C2). Tighten two
HIDDEN CAMS.
å
Fasten the BACK BRACE (E) to the LEFT END (B2).
Tighten two HIDDEN CAMS.
Start Tighten
Arrow
Minimum
190 degrees
Caution
Risk of damage or
injury. HIDDEN CAMS
must be completely
tightened. HIDDEN
CAMS that are not
completely tightened
may loosen, and parts
may separate. To
completely tighten:
Arrow
Maximum
210 degrees
B2
Finished edge
E
C2
Surface with HIDDEN CAMS
Surface
with
HIDDEN
CAMS
Rounded edge
Surface with holes
These edges must be even.
Do not stand the unit upright without the
BACK fastened. The unit may collapse.
Caution
