Sauder 423408 - Product Components; Part Identification; Hardware Identification

Part Identifi cation
å While not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identifi cation to help identify similar parts.
Now you know
our ABCs.
A END (2)
B TOP (1)
C BOTTOM (1)
D BRACE (1)
Page 3www.sauder.com423408
A
B
C
D
A
Hardware Identifi cation
å Screws are shown actual size. You may receive extra hardware with your unit.
SILVER 7/16" PAN HEAD SCREW - 20
10
SILVER 1-1/2" FLAT HEAD SCREW - 6
9
(Refer to the last step for proper location and application)
WARNING LABEL - 1
6
5
22,68
22,68
25 lbs. 11 kg 11 kg
7
CAM COVER - 6
SCREW COVER - 2
8
WOOD DOWEL - 1
3
HIDDEN CAM - 6
1
CAM SCREW - 6
2
CASTER - 2
4
LOCKING CASTER - 2
5
