sauter FC - 1 General Specifications; Overview; LCD Screen

4 FC-BA-e-1410
1 General Specifications
1.1 Overview
1.2 LCD Screen
① Test mode icon:
：Track, ：Peak, ：Preset
② Battery icon: Indicating the battery level or charging status, flashes if the
gauge needs to be recharged
③ Preset Mode Test status mark ：
The measured value between the upper limit and lower limit that is OK;
:The measured value between the lower limit and 75% of the lower limit,
which means it is below the lower limit
Fig 1-1
Fig 1-2
