Copyright © 2018 Savant Systems, LLCEntry Service with 2N Door Stations Deployment Guide
009-1540-00 | 181026
5 of 29
3. Equipment Overview
This section gives a basic overview of the 2N Door Stations that Savant sells. For detailed information on the individual products see the Documentation tab
on the Integrator store on Savant.com.
3.1. Box Contents and Specifications
Documentation is available on the Savant Customer Community, See the 2N Door Station Integration with Savant Application Note.
3.2. Installation
Follow the installation manual included with the product.
Download links for the installation documentation
– Verso Installation Manual
– Solo Installation Manual
– Force Installation Manual
These documents can also be found on the Savant Customer Community, see the 2N Door Station Integration with Savant Application Note.
3.3. Door Station Single Height (2N IP Solo)
Speaker Audio Output.
Microphone Audio Input.
IR LED Infrared LED for the night vision camera.
Camera Wide-angle IP camera used to view who/what is at the entry.
LED Status
Icons
Door Open: Attached door lock is been opened.
Locked: Zone is locked.
Active Call: An active call is in progress.
Ringing: Displays when I call is being made to the Door Station.
Name Plate
Removable clear plate to place Name/Address information behind with
White Back-light.
Call Button To start a call from the intercom
Front Panel
Speaker
Camera
Call Button
Name Plate
IR LED
LED Status
Icons
