5.4.!Network Connection
The Pro Audio 4 uses a standard RJ-45 port complying with IEEE 802.3 Ethernet standards. This port also supports Audio Video Bridging (AVB)
over Ethernet (AVB, IEEE 802.1). Up to three Pro Audio 4 units can be connected using AVB compliant switching, providing up to 18 zones of
distributed audio (12 amplified zones and 6 preamp zones). For more information on this, see the Expansion section.
5.5.!AC Power Connection
SURGE PROTECTION!
Use a surge-protected circuit for all components and power supplies requiring 100/240V (AC 50/60 Hz) 2.7A source power.
ELECTRICAL DISCONNECT!
The source power outlet and power supply input power sockets should be easily accessible to disconnect power in the event of an electrical hazard or
malfunction.
Power Management Recommendations
Savant recommends a pure sine wave uninterruptible power supply (UPS) with the ability to shut down the Savant Host before the battery runs out
of power. Never remove power from the Savant Pro Audio 4 before shutting it down.
