Infinity and Infinity HD Planning Guide Part No. 000783, 24-m09-2015
For Infinity (3 HP pump unit)
For Infinity HD (5 HP pump unit)
Disconnect Switch Types & Accessories Cutler Hammer Federal Pioneer Siemens
1 Phase 3 H.P. Pump Unit
2 Pole 240V 1 PH 1HD221N 1322SN ID321
Required Auxiliary Contact DS16CP E1K-1AEV-W94 MSSAK 116
Required Type “D” Fuse (Buss type “FRN” or equal) 2@30 amp 2@30 amp 2@30 amp
3 Phase 3 H.P. Pump Unit
3 Pole 208V 3 PH 1HD321N 1332SN ID321
Required Auxiliary Contact DS16CP E1K-1AEV-W94 MSSAK 116
Required Type “D” Fuse (Buss type “FRN” or equal) 3@20 amp 3@20 amp 3@20 amp
Cab Lighting
1 Pole Solid Neutral 120V 1 PH GP 111N 86211 CFN 211
Required Type “D” Fuse (Buss type “T” or equal) 1@15 amp 1@15 amp 1@15 amp
Disconnect Switch Types & Accessories Cutler Hammer Federal Pioneer Siemens
1 Phase 5 H.P. Pump Unit
2 Pole 240V 1 PH 1HD221N 1322SN ID321
Required Auxiliary Contact DS16CP E1K-1AEV-W94 MSSAK 116
Required Type “D” Fuse (Buss type “FRN” or equal) 2@40 amp 2@40 amp 2@40 amp
3 Phase 5 H.P. Pump Unit
3 Pole 208V 3 PH 1HD321N 1332SN ID321
Required Auxiliary Contact DS16CP E1K-1AEV-W94 MSSAK 116
Required Type “D” Fuse (Buss type “FRN” or equal) 3@30 amp 3@30 amp 3@30 amp
Cab Lighting
1 Pole Solid Neutral 120V 1 PH GP 111N 86211 CFN 211
Required Type “D” Fuse (Buss type “T” or equal) 1@15 amp 1@15 amp 1@15 amp
