COMPACT TABLE SAW

SawStop.com

CTS

™

Owner’s Manual

CTS-120A60 / CTS-120A60A / CTS-230A50I

Table of Contents

Questions and Answers

M
Michael MedinaAug 21, 2025
What to do if my SawStop CTS-120A60A motor stopped unexpectedly?
- D
  David FieldsAug 21, 2025
  If the motor stopped unexpectedly during use, but the brake didn't activate, consider these possibilities: * The Start/Stop paddle may have been bumped. Ensure it's in the OFF position, and then restart the saw. * The material being cut might be overloading the safety detection system (e.g., green or wet wood). Use a different wood or cut in Bypass Mode. * There may have been a temporary loss of electrical power. Ensure the electrical supply is on and that you are using the correct voltage. * The brake cartridge could be faulty. Replace it with a new one. * The arbor nut could be loose. Check its tightness and tighten if necessary.
D
Daniel DiazAug 23, 2025
Why did the brake activate on my SawStop Saw without contact?
- S
  spencer68Aug 25, 2025
  The brake may have activated without contact for the following reasons: * An electrically conductive material contacted the blade, arbor, or arbor pulley. Ensure no metal or other conductive material is touching these parts. Use Bypass Mode to cut conductive materials. * The spreader or riving knife came into contact with the blade. Ensure they are aligned and securely clamped in place, with a 4-8 mm gap between the blade and the spreader or riving knife. * The blade made contact with the brake pawl. Ensure there is a 1.5 mm to 3 mm gap between the teeth of the blade and the closest point on the brake cartridge. Use only a 10” blade.
S
Samantha ThompsonAug 26, 2025
What to do if I cannot remove the cartridge key from my SawStop CTS-120A60A?
- A
  ashleybanksAug 26, 2025
  If you cannot remove the cartridge key: * The retraction mechanism might not be reset, blocking access to the brake cartridge. Reset it by fully lowering the blade by turning the elevation wheel counterclockwise until it stops. You should hear the retraction mechanism snap back into the normal operating position. * The cartridge key may not be turned to the UNLOCKED position. Turn the key clockwise until it stops. * The shaft of the cartridge key might be binding in the cartridge or on the cartridge mounting bracket. Try turning and removing the key while pressing upward or downward on the key or cartridge.
G
Gary SmithAug 27, 2025
Why won't my SawStop Saw motor start, the red light is on, and the green light is off?
- N
  Nicolas OrozcoAug 28, 2025
  If the motor won't start, the power switch is on, the red status light is solid, and the green status light is off, the brake cartridge may be faulty. Replace it with a new one.
B
brendaalvarezAug 29, 2025
Why does my SawStop Saw motor start slowly?
- A
  ahorneAug 30, 2025
  If the motor starts slowly or fails to reach full operating speed, the electrical supply voltage might be too low. Ensure the correct voltage is supplied to the saw.
T
Troy BaldwinSep 1, 2025
Why does the blade hit the brake pawl on my SawStop CTS-120A60A Saw during installation?
- C
  Carol HuynhSep 1, 2025
  If the blade hits the brake pawl during installation, the blade might be the wrong size. Use only a 10" blade.
T
Tiffany WolfSep 3, 2025
Why does raising or lowering the blade on my SawStop CTS-120A60A Saw feel rough?
- J
  Jeremy ReyesSep 3, 2025
  If raising or lowering the blade feels or sounds rough, the alignment block might be worn. Replace the alignment block.
A
andreadouglasSep 5, 2025
What to do if I left wrenches inside SawStop Saw?
- C
  Connie DavisSep 5, 2025
  If you dropped tools or parts during blade or cartridge change process or adjustment: * Open access door to retrieve parts. * Tilt saw to dump parts / wrenches out dust exhaust port. Do not start the saw before all parts have been removed. Leaving parts in the saw body might damage the product or trigger an unintended activation.
A
Angela MitchellSep 7, 2025
What to do if SawStop CTS-120A60A motor stopped unexpectedly?
- S
  Shelly BrownSep 7, 2025
  If the motor of your SawStop Saw stops unexpectedly during operation without brake activation, there are several potential causes: * The Start/Stop paddle may have been accidentally bumped. Ensure it's in the OFF position and restart the saw. * The material you're cutting might be overloading the safety detection system, especially with green or wet wood. Try using a different type of wood or switch to Bypass Mode. * There may have been a temporary loss of electrical power. Check that the saw is properly connected to a power supply with the correct voltage. * The brake cartridge could be faulty and may need replacement.
B
boyerjessicaSep 9, 2025
How to troubleshoot SawStop Saw when motor won't start and status lights are off?
- J
  Jacob RileySep 10, 2025
  If the motor on your SawStop Saw won't start and both status lights on the switch box are off, consider these possibilities: * The saw may not be receiving power. Verify that the electrical supply to the saw is on and that the correct voltage is being supplied. * A brake cartridge may not be installed. Install the brake cartridge. * The installed brake cartridge may be defective. Replace it with a new one.

SawStop CTS-120A60A Specifications

General

Brand	SawStop
Model	CTS-120A60A
Category	Saw
Language	English
