38 1/4” x 3/4” x 0.08” Washer TSG-FDC-038 1
39 Spring Tension Knob TSG-FDC-039 1
40 1/4”-20 x 4” Eye Bolt TSG-FDC-040 1
41 Floating Guard Spring TSG-FDC-041 1
42 Tension Plate Spacer TSG-FDC-042 2
43 M5 x 0.8 Lock Nut TSG-FDC-043 1
44 Floating Guard Tension Plate TSG-FDC-044 1
45 1/4”-20 x 1/2” Hex Head Bolt TSG-FDC-045 2
46 Blade Guard Warning Label TSG-FDC-046 1
47 M5 x 0.8 x 45 Hex Head Bolt TSG-FDC-047 1
48 M6 x 1.0 x 40 Button Head Socket Screw TSG-FDC-048 1
49 M6 x 1.0 Nylok Nut TSG-FDC-049 1
50 Hose Clamp TSG-FDC-050 2
51 Dust Collection Hose TSG-FDC-051 1
52 M5 x 0.8 Lock Nut TSG-FDC-052 3
53 1/4”-20 Lock Nut TSG-FDC-053 6
54 M10 x 20 x 1.5 Plastic Washer TSG-FDC-054 6
55 M5 x 16 x 0.7 Washer TSG-FDC-055 4
56 Tension Plate Linkage TSG-FDC-056 2
57 M5 x 0.8 x 16 Hex Head Bolt TSG-FDC-057 3
58 Floating Guard Link Plate TSG-FDC-058 4
59 1/4"-20 Floating Guard Lock Handle TSG-FDC-059 1
60 1/4” x 3/4” x 0.08” Washer TSG-FDC-060 4
61 1/4”-20 Lock Nut TSG-FDC-061 2
62 Floating Guard Handle Mounting Plate TSG-FDC-062 2
63 M4 x 0.7 Lock Nut TSG-FDC-063 2
64 Floating Guard Handle TSG-FDC-064 1
65 Floating Blade Guard TSG-FDC-065 1
66 M4 x 0.7 x 12 Pan Head Phillips Screw TSG-FDC-066 2
67 Floating Guard Mounting Bracket TSG-FDC-067 1
68 1/4”-20 x 1/2” Hex Head Bolt TSG-FDC-068 2
69 1/4"-20 x 2-1/4" Carriage Head Bolt TSG-FDC-069 3
Parts List
