TSG-FDC OWNER’S MANUAL
Parts List
No. Description Part No. Qty.
1 Outer Dust Tube Sleeve TSG-FDC-001 1
2 1/4"-20 x 3/8" Pan Head Phillips Screw TSG-FDC-002 1
3 Inner Dust Tube TSG-FDC-003 1
4 M5 x 0.8 x 12 Button Head Socket Screw TSG-FDC-004 1
5 Inner Dust Tube Guide Bar TSG-FDC-005 1
6 M5 x 0.8 x 10 Button Head Socket Screw TSG-FDC-006 1
7 Outer Dust Tube TSG-FDC-007 1
8 M5 x 0.8 x 25 Button Head Socket Screw TSG-FDC-008 1
9 SawStop Label TSG-FDC-009 1
10 1/4"-20 Inner Dust Tube Lock Knob TSG-FDC-010 1
11 Dust Collection Guard Mounting Bracket TSG-FDC-011 1
12 M6 x 19 x 1 Washer TSG-FDC-012 8
13 M6 x 1.0 Nut TSG-FDC-013 4
14 3/8"-16 x 4" Carriage Head Bolt TSG-FDC-014 1
15 M6 x 1.0 x 40 Hex Head Bolt TSG-FDC-015 4
16 3/8"-16 Lock Nut TSG-FDC-016 1
17 5/16"-18 Nut TSG-FDC-017 1
18 5/16”-18 x 1-1/2” Hex Head Bolt TSG-FDC-018 1
19 5/16" Push Nut TSG-FDC-019 2
20 Dust Tube Pivot Plate TSG-FDC-020 2
21 3/8"-16 Dust Tube Barrel Nut TSG-FDC-021 1
22 3/8"-16 Nut TSG-FDC-022 2
23 3/8"-16 Dust Tube Lock Knob TSG-FDC-023 1
24 Dust Tube Pivot Spacer TSG-FDC-024 2
25 1/4"-20 Extension Leg Lock Knob TSG-FDC-025 2
26 Extension Leg TSG-FDC-026 1
27 Leg End Cap TSG-FDC-027 1
28 1/4" Lock Washer TSG-FDC-028 6
29 1/4”-20 Nut TSG-FDC-029 8
30 1/4”-20 x 1/2” Hex Head Bolt TSG-FDC-030 4
31 Leg Support Bracket TSG-FDC-031 2
32 Leg Support Mounting Bracket TSG-FDC-032 2
33 M5 x 12 x 1 Washer TSG-FDC-033 2
34 M5 x 2.1 x 32 Button Head Phillips Screw TSG-FDC-034 2
35 1/4"-20 x 3/4" Flat Head Socket Screw TSG-FDC-035 2
36 1/4”-20 x 4” Eye Bolt TSG-FDC-036 2
37 Floating Guard Support Arm TSG-FDC-037 1
