General
Conguration (Device Congurator)
8-2
8
8.2 General
This chapter describes how the Saia PG5
®
Device Congurator is used.
The Device Congurator denes:
- cyclic media mapping to enable a link between peripheral I/O module values
and the device resources (e. g. PCD ags and register).
- direct access to programming instructions to read or transfer values from the
peripheral module.
The I/O handling is always activated for the PCD1.M2220-C15 via direct access,
there is no bit access command. The minimum access range is “byte”. It is there-
fore recommended to use media mapping to read or write all the I/O channels.
For further details, see the help text for the Device Congurator.
