1 Graphic overview
1.1 Go to...
The graphic overview shows some of the most important points regarding the op-
erating instructions for the PCD1.M2220-C15.
Click the descriptive texts for the connections to jump direct to the corresponding
section of the document.
The numbers separated by full stops correspond to the chapter numbers.
M1
2 free slots with SPI (fast
serial bus) for PCD2
plug-in module 6.2
Slot for memory
module 3.5.4
Terminals for on-board in-
puts/outputs and watchdog
relay 6.1.1
Terminating resistors
(RS-485) 5.2.3
Operating LEDs
3.7
Power supply
2.5.2
On-board RS-485
interfaces 5.2.3
USB connection
5.2.1
RUN/STOP
button 3.8
Ethernet connection
(2 port switch) 5.2.2
RS-485 LEDs
5.2.3
Ethernet LEDs
5.2.2
DI0... 3 LEDs
6.1.2
AI0… 1 LEDs
6.1.3
WD LED
3.9
FW
Firmware
3.4
