Network Interface Layout
Physical NIC port congurations for 1 GbE and 10 GbE node options.
HC1100 Series
1 GbE port conguration for the HC1100, HC1150, HC1150D, and HC1150DF models.
10 GbE port congurations for the HC1100, HC1150, HC1150D, and HC1150DF models.
HC2100 Series
1 GbE port conguration for the HC2100 model.
