SCAN 57 - Assembly; Dimension Sketch Scan 57; Scan 57 Variants; Unpacking

Unpacking
We recommend that you leave the protective film on the stove until
fitting is complete.
Service package
The service package contains the following:
• Fitting for flue collar (not used for this Scan model)
• Seal
• Safety fitting (not used for this Scan model)
• Plastic plugs for transport safety hole at the bottom of the
stove (not used for this Scan model)
• Various tools
• Glove
• Fire starters for first lighting
4
ASSEMBLY
Accessories
• Shaped floor plate, glass or steel (not on stove with revolving
base)
• Floor plate, steel
• Fresh air solution
Scan 57 variants
The Scan 57 is found in 2 variants:
Scan 57 with fixed base.
Scan 57 with revolving base.
1
0
3
9
9
8
8
*
1129 290**
711
2
9
0
979 461
Dimension sketch Scan 57
* Height to start of flue pipe
** Centre fresh air inlet
