SCAN 57 - Positioning your wood-burning stove; Distance to flammable walls

6
ASSEMBLY
Distance to flammable walls
200
2
0
0
4
5
7
45° Corner installation
Parallel rear wall installation
Positioning your wood-burning stove
The wood-burning stove must be set up so that the stove itself, the flue pipe, and the chimney can all be cleaned.
Position near to non-flammable walls
When positioning near a non-flammable wall, we recommend you keep a minimum distance of 50 mm between the rear of the product and
the wall for cleaning purposes.
Distance to furniture: 1100 mm
But please check to avoid furniture or other furnishings being dried out due to being too close to the stove.
Revolving base
If you have chosen the Scan 57 with revolving base, the wood-burning stove is delivered with restricted rotation (45°).
8
0
80
6
0
7
800
5
0
3
9
5
