11
ASSEMBLY
TOOLS NEEDED FOR MOUNTING OF THE STOVE
¬ Spirit level ¬ Open-end spanner
¬ Cutting nippers
LOOSE PARTS
The loose parts are located in the stove's ash drawer.
¬ Glove ¬ Seal for the connecting piece
¬ 4 pcs. screws for fastening the connecting piece ¬ Scan 65-3 and Scan 65-4: 4,5 m gasket
¬ Fresh air intake ¬ Scan 65-7 and Scan 65-8: 7 m gasket
¬ 1 pcs. screw M5x6, must be placed for United Kingdom
ADDITIONAL ACCESSORIES
¬ Small shaped floor plate in glass or steel ¬ Large shaped floor plate in glass or steel
¬ Natural stones top plate for stove with rear outlet ¬ Natural stones top plate for stove with top outlet
¬ Scan 65-7/8 and 65-9/10: Heat accumulating stones
DISPOSAL OF PACKAGING
Your Scan stove may come supplied with the following packaging:
Wood packaging
The wood packaging can be reused and after final use can be incinerated as a CO
2
neutral
product or sent for recycling.
Polystyrene top Send for recycling or waste disposal
Foam Send for recycling or waste disposal
Plastic bags Send for recycling or waste disposal
Stretch/plastic film Send for recycling or waste disposal
FRESH AIR INTAKE
In a well-insulated house, the air used up by the burning process has to be replaced. This particularly applies to houses with
mechanical ventilation. There are different ways of making sure that an air exchange takes place. The most important thing is to
ensure that there is a supply of air to the room where the wood stove is located. The external wall vent must be located as close
to the wood stove as possible, and you must be able to close it when you are not using the wood stove.
National and local building regulations must be followed with regard to the connection of fresh-air intake.
