MOUNTING THE UK - SCREW
UK ONLY! IMPORTANT!
Scan 65 has been recommented as suitable for use in smoke control areas when burning wood logs and when fitted with a
mechanical stop to prevent secondary air control closure beyond the 35mm open position.
NOTE: In order to a achieve this, the screw (M5 x 6)
must be placed as shown in the pictures, to prevent
that the secondary air valve can be closed completely.
LOAD-BEARING FOUNDATION
All items in our product range come under the category of lightweight fireplaces and stoves and do not normally require any rein-
forcement of the beam structure. They can be positioned on ordinary beams/floor.
You should of course make sure that the foundation on which the stove is positioned can indeed support the weight of the stove
and, where applicable, a steel chimney, if you have opted for this solution.
FLOOR PLATE
If you are placing the stove on a flammable floor, you must comply with the national and local regulations on the size of any
non-flammable subsurface required to cover the floor around the stove.
Your local Scan dealer can advise you on regulations concerning protection of flammable materials in the vicinity of your stove.
The floor plate’s function is to protect the floor and flammable material against any sparks that may occur. A floor plate can be
made of steel or glass, but the stove can also be erected on clinker concrete, natural stone or similar materials.
This Scan wood-burning stove has an integrated floor plate at the bottom and can thus be erected directly on flammable
material without the need for further protection underneath the stove.
